Summarization of Contents
FUSION CULTURE
Brand Philosophy
Brand philosophy about making noise and pushing limits in car audio.
POWERPLANT
Product Introduction
Introduction to the PowerPlant amplifier range, highlighting performance and reliability.
AMPLIFIER FEATURES
Key Amplifier Features
Lists design aspects like D-Class, MOSFET, RCA ports, crossovers, bass boost, and protection circuitry.
AMPLIFIER SPECIFICATIONS
Technical Specifications Table
Comparison of PowerPlant amplifier models across various technical parameters.
AMPLIFIER RATINGS
Power Output Ratings by Model
Lists RMS power outputs for each model at 4 Ohms, 2 Ohms, and bridged configurations.
INSTALLATION
Installation Warnings
Crucial safety and operational warnings to follow during amplifier installation.
WIRING
Power Cable Calculator
Chart to determine appropriate cable gauges based on amperage and length.
CONNECTION
Power and Ground Connection
Step-by-step guide for connecting the power and ground terminals on the amplifier.
REMOTE TURN-ON
Speaker Load and Wiring
Information on proper speaker impedance and wiring connections for optimal performance.
LOW LEVEL INPUTS
Level Control Adjustment
Steps to match the amplifier's input level to the head unit's output for optimal sound.
CONTROL DESCRIPTIONS: MONOBLOCK AMPLIFIER
Power and Status LEDs
Displays amplifier status: Green for powered up, Red for faults.
Bass Boost
Variable control for bass boost at 45Hz, from 0 to +12dB gain.
Phase Switch
Selects phase between 0 or 180 degrees for subwoofer direction adjustment.
Low Pass Filter
Filters out mid to high frequencies, set at or below 100Hz to protect speakers.
Subsonic Filter
Filters out sub-bass frequencies below a set point at 12dB/Octave.
Level Control
Adjusts input signal level to match head unit output, preventing distortion.
RCA Input
Connects to a head unit with a low-level output for audio signal input.
RCA Output
Pass-thru connection for a secondary amplifier, mirroring input signal characteristics.
Ground Input
Connects to the vehicle chassis using a 4 gauge power cable for grounding.
Remote Input
Connects to a switched +12V source to turn the amplifier on and off.
+12V Input
Connects directly to the vehicle battery positive terminal with an inline fuse.
Fuses
Specifies the correct type and quantity of fuses required for the amplifier.
Speaker Output
Connection points for speakers; refer to wiring diagrams for correct hookup.
