SPLIT TYPE ROOM AIR
CONDITIONER
WALL MOUNTED
Models
Indoor unit
ASH14FSBCW
ASH14USBCW
CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 1
OUTLINE AND DIMENSIONS . . . . . . . . . . . . . . 2
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . 4
PCB CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . .
ERROR DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . .
DISASSEMBLY ILLUSTRATION . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
type
Outdoor unit
AOH14FSBC
AOH14USBC
. . . . . . . 3
6
8
