OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
O
M
PERATING
ANUAL
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ROOM AIR CONDITIONER
ΕΓΧΕΙΡΙ∆ΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
MANUAL DE INSTRUÇÕES
MULTI SPLIT TYPE
(4 ROOMS)
HEAT & COOL MODEL
(REVERSE CYCLE)
INDOOR UNIT
ASH9QM
ASH12QM
OUTDOOR UNIT
AOH30QMAM4
KEEP THIS OPERATION MANUAL
FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED
P/N9372467015
Advertisement
Table of Contents
Related Manuals for General INVERTER ASH9QM
Summary of Contents for General INVERTER ASH9QM
- Page 1 MANUALE DI ISTRUZIONI ROOM AIR CONDITIONER ΕΓΧΕΙΡΙ∆ΙΟ ΛΕΙΤΟΥΡΓΙΑΣ MANUAL DE INSTRUÇÕES MULTI SPLIT TYPE (4 ROOMS) HEAT & COOL MODEL (REVERSE CYCLE) INDOOR UNIT ASH9QM ASH12QM OUTDOOR UNIT AOH30QMAM4 KEEP THIS OPERATION MANUAL FOR FUTURE REFERENCE FUJITSU GENERAL LIMITED P/N9372467015...
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ........En-1 ADJUSTING THE DIRECTION OF FEATURES AND FUNCTIONS ......En-2 AIR CIRCULATION ..........En-10 NAME OF PARTS ..........En-3 SWING OPERATION ......... En-11 PREPARATION ............ En-5 MANUAL AUTO OPERATION ......En-11 OPERATION ............En-6 CLEANING AND CARE ........En-12 TIMER OPERATION .......... -
Page 3: Features And Functions
FEATURES AND FUNCTIONS AUTOMATIC OPERATION SWING OPERATION Merely press the START/STOP button, and the unit will be- The Air Flow Direction Louvers swings automatically up and gin automatic operation in either the Heating, Cooling, Dry down so that the air speeds to every nook and corner of or Monitor modes as appropriate, in accordance with the your room. -
Page 4: Name Of Parts
NAME OF PARTS Fig. 1 Fig. 2 Fig. 3 Fig. 5 Fig. 4 Fig. 6 Fig. 8 To facilitate explanation, the accompanying illustra- tion has been drawn to show all possible indicators; in actual operation, however, the display will only show those indicators appropriate to the current op- eration. - Page 5 Fig. 1 Indoor Unit Fig. 6 Remote Control Unit 1 Operating Control Panel (Fig. 2) H SLEEP button 2 POWER Switch I MASTER CONTROL button 3 MANUAL AUTO button J SET TEMP./SET TIME buttons ( K Signal Transmitter 4 Remote Control Signal Receiver L TIMER button 5 Indicator Lamps (Fig.
-
Page 6: Preparation
PREPARATION CAUTION! Turn on the Power G Take care to prevent infants from accidentally swallowing batteries. Turn on the circuit breaker. G When not using the remote control unit for an extended period, remove the Set the POWER switch (Fig. 2 2) to ON. batteries to avoid possible leakage and damage to the unit. -
Page 7: Operation
OPERATION To Select Mode Operation Press the START/STOP button (Fig.6 N). The indoor unit’s OPERATION indicator lamp (red) (Fig. 3 6) will light. The air conditioner will start operating. Press the MASTER CONTROL button (Fig.6 I) to se- lect the desired mode. Each time the button is pressed, the mode will change in the following order: AUTO... - Page 8 OPERATION About Mode Operation AUTO: G Depending on the room temperature at the time operation begins, the operating mode will be switched automatically as shown in the accompanying table. Also, depending on the operating mode, the room temperature setting will cause the “standard”...
-
Page 9: Timer Operation
TIMER OPERATION Before using the timer function, be sure that the Remote Control Unit is set to the correct current time (See page 5). To Use the ON timer or OFF timer To Cancel the Timer Press the START/STOP button (Fig. 6 N) Use the TIMER button to select “TIMER (if the unit is already operating, proceed to step 2). -
Page 10: Sleep Timer Operation
SLEEP TIMER OPERATION Unlike other timer function , the SLEEP timer is use to set the length of time until air conditioner operate is stopped. To Use the SLEEP timer To Cancel the Timer: While the air conditioner is operating or stopped, press the Use the TIMER button to select “TIMER SLEEP button (Fig. -
Page 11: Adjusting The Direction Of Air Circulation
ADJUSTING THE DIRECTION OF AIR CIRCULATION Vertical (up-down) direction of airflow is adjusted by pressing the Remote Control Unit’s AIR FLOW DIRECTION button. Hori- zontal (right-left) airflow direction is adjusted manually, by moving the Air Flow Direction Louvers. Whenever making horizontal airflow adjustments, start air conditioner operation and be sure that the vertical air direction louvers are stopped. -
Page 12: Swing Operation
SWING OPERATION Begin air conditioner operation before performing this procedure. To select SWING Operation Press the SWING LOUVER button (Fig. 6 P). The SWING indicator lamp (orange) (Fig. 3 8) will light. In this mode, the Air Flow Direction Louvers will swing automatically to direct the airflow both up and down. -
Page 13: Cleaning And Care
CLEANING AND CARE G Before cleaning the air conditioner, be sure to turn it off and disconnect the power supply cord. CAUTION! G Be sure the intake grille (Fig. 1 9) is installed securely. G When removing and replacing the air filters, be sure not to touch the heat exchanger, as per- sonal injury may result. - Page 14 CLEANING AND CARE Air Cleaning Filter Installation Replacing dirty Air cleaning filters 1. Open the intake grille and remove the air Please purchase the separately sold replacement air clean- filters. ing filters (type APS-02F) and install them. 1. Open the intake grille and remove the air Intake grille filters.
- Page 15 TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the cir- WARNING! cuit breaker, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source.
-
Page 16: Troubleshooting
TROUBLESHOOTING Symptom Items to check See Page G Has the circuit breaker been turn off? CHECK ONCE Doesn’t operate at all: MORE G Has there been a power failure? — G Has a fuse blown out, or a circuit breaker been tripped? G Is the main POWER switch set to the OFF position? G Is the timer operating? G Is the air filter dirty? - Page 17 OPERATING TIPS In Event of Power Interruption AUTO Restart G If a power failure occurs during TIMER operation, the timer G The air conditioner power has been interrupted by a power will be reset and the unit will begin (or stop) operation at failure.
- Page 18 OPERATING TIPS Multi-type Air conditioner This indoor unit can be connected to a multi-type outdoor unit. The multi-type air conditioner allows multiple indoor units to be operated in multiple locations. The indoor units may be operated simultaneously, in accordance with their respective output.
-
Page 19: Specifications
SPECIFICATIONS INDOOR UNIT ASH9QM ASH12QM ASH18QM ASH24QM [kW] Cooling Capacity [BTU] 9,200 12,000 17,800 23,600 [kW] Heating Capacity [BTU] 11,300 13,700 21,200 28,000 High [dB (A)] [dB (A)] Noise Level [dB (A)] Quiet [dB (A)] H × W × D 260 ×...
