Audio connections to Vortex are unbal-
anced and should be made with high quality
shielded cables with 1/4" tip-sleeve phone
jacks at the Vortex end.
Vortex is a true stereo processor. Left and
right inputs are processsed separately. The
chart to the right shows the processing path
of each preset.
Even if you are using a mono input, take
advantage of the stereo outputs. All Vortex
effects are designed to be mono compatible
and to maximize the spatial characteristics
of each effect. If mono output is required, use
the right output jack. The left and right sig-
nals are summed internally when only the
right output is used.
Stereo In Dual Stereo In
Stereo Out Stereo Out
Reflexion A/B
1
Atmosphere A/B
2
3
4
Aerosol A/B
5
Mosaic A
6
Maze B
7
8
Deja Vu A/B
9
Choir A
10
Shimmer A/B
11
Sweep A/B
12
13 Shadow A
Cycloid A/B
14
Bleen A
15 Bleen B
Fractal A/B
16
6

Audio Connections

Dual Mono In Dual Mono In
Stereo Out Dual Mono Out
Orbits A/B
Duo A
Duo B
Mono In
Stereo Out
Centrifuge A/B
Mosaic B
Maze A
Choir B
Shadow B
