A/B Relay Switch - Lexicon VORTEX User Manual

Vortex is equipped with an electrically iso-
lated analog switch that allows remote con-
trol of guitar amplifier lead/rhythm channel
selection. Simply connect a standard 1/4"
guitar cable between the Vortex rear panel A/
B relay switch and the A/B switching input on
your amp.
Both the front panel A/B button, and the
footswitch A/B control will activate this
switch, allowing you to simultaneously
switch effects and amplifier settings.
For example, if your amp channel A corre-
sponds to lead, and channel B to rhythm, you
can load Vortex's A registers with effects you
want to use on leads, and load the B registers
with rhythm effects. Now, a single tap on the
A/B footswitch will coordinate switching be-
tween lead effects on your A channel and
rhythm effects on your B channel.
8

A/B Relay Switch

Any amplifier with a channel switching
feature and a footswitch connection can be
connected to the rear panel A/B relay con-
nector on Vortex. The switch functions as
follows:
Mono plug* Stereo plug
A switch closed sleeve tied to Tip
B switch open sleeve tied to Ring
* To switch polarity, use a stereo plug into
Vortex, with a mono plug going into the amp.
Attach the two wires to the connector sleeve
and ring so that A = open and B = closed.
