Multiple Patches to a Parameter
The Reflex patching system supports the
patching of multiple control sources to a
single parameter. To create multiple
patches, simply repeat the patching proce-
dure to a given parameter, altering only the
control source.
In Advanced Programming Mode, the
number of patches made to a displayed
parameter is indicated by a sequence of 1, 2
3, or 4 quick flashes of the decimal point
patch indicator.
It is important to note that when multiple
control sources are used simultaneously,
their values are summed .
As an example, suppose you have both
Foot Pedal (controller 4) and Data Entry
(controller 6) patched to control the Effects
Level parameter. If the footpedal is output-
ting a controller value of 60 while the data
entry controller is producing a value of 15,
the Effects Level parameter will respond to
a controller value of 75 (60+15).
39
Negative scaling will have a subtractive
effect on the controller value sum if mapped
to the same parameter.
