Related Manuals for Thermaltake Armor-VA8000BWS
Summarization of Contents
Chapter1 Product Introduction
1.1 Specification
Details specifications for VA8000SWA and VA8000BWS models, including dimensions, cooling, drive bays, materials, and expansion slots.
Chapter2 Case Mechanical Operation
2.1 How to open the side panel
Instructions on how to open the side panel of the computer case, including unlocking and swinging it open.
2.2 Installing 5.25" Device
Step-by-step guide on installing a 5.25-inch device, involving tool-free clips and drive bay covers.
2.3 Installing 3.5" HDD
Instructions for installing a 3.5-inch Hard Disk Drive (HDD) into the case, including removing the HDD cage.
2.4 Removable 12cm Fan cage with 3HDD
Guide on how to remove and relocate a 12cm fan cage that accommodates three HDDs.
2.5 Installing 3.5" HDD (For 12cm Fan Cage)
Detailed steps for installing a 3.5-inch HDD specifically into the 12cm fan cage.
2.6 5.25" to 3.5" Drive Tray Device Installation.
Instructions for installing a 5.25-inch to 3.5-inch drive tray, including device tray removal and HDD installation.
2.7 Installing 3.5" Device to Drive Tray With Power Button
Guide to installing a 3.5-inch device into a drive tray that includes a power button function.
2.8 Installing Power Supply
Detailed steps for installing the power supply unit (PSU) into the case, including locating and using the PSU supporter.
2.9 Installing the fan on top of the case
Instructions for installing a fan onto the top of the computer case using clips and mounting holes.
2.10 How to remove the fan & fan holder
Guide on how to remove fans and their holders from the case, covering 12cm and 9cm rear fans.
2.11 Air Cooling System
Overview of the air cooling system, detailing fan locations, sizes, and airflow directions within the chassis.
2.12 BTX Upgraded Kits
Information about BTX upgraded kits, including the rear plate, SRM, and the upgraded kit box.
2.13 PCI slot tool-free function operation
Instructions on how to operate the tool-free function for PCI slots, including opening clips and removing brackets.
Chapter3 Motherboard & Leads Installation
3.1 Motherboard Installation
Guidance on installing motherboards into the case, covering placement direction, standoffs, and component installation order.
3.2 Case LED connections
Instructions for connecting case LEDs and switch leads (POWER SW, POWER LED, HDD LED, RESET SW, SPEAKER) to the motherboard.
3.3 USB2.0 & IEEE1394 Firewire connection
Details on connecting USB 2.0 and IEEE1394 Firewire ports to the motherboard, including pinouts.
3.4 Ear & MIC connections
Guide for connecting front panel audio connectors (Ear & MIC) to the motherboard, including pinouts.
3.5 Case open alarm function (Intrusion switch)
Instructions for connecting the case intrusion switch to the motherboard for an open alarm function.
Chapter4 Other
4.1 Silent Purepower™ power supply (optional)
Information on the Thermaltake Silent Purepower power supply, detailing its features like automatic fan control and protection functions.
