Summary of Contents for Samson RS12HD

  • Page 1 RS10HD RS12HD RS15HD RS215HD RS10mHD RS12mHD RS15mHD...
  • Page 2 Safety Instructions/Consignes de sécurité/Sicherheitsvorkehrungen/Instrucciones de seguridad WARNING: To reduce the risk of fire or electric shock, do not expose this unit to rain ATTENTION: Pour éviter tout risque d’électrocution ou d’incendie, ne pas exposer or moisture. To reduce the hazard of electrical shock, do not remove cover or back. cet appareil à...

  • Page 3: Table Of Contents

    Positioning the Resound HD Setting up your Resound HD Resound HD Wiring Guide Specifications 10 - 11 Notes Copyright 2008, Samson Technologies Corp.. Printed January, 2008 v1.0 Samson Technologies Corp. 45 Gilpin Avenue Hauppauge, New York 11788-8816 Phone: 1-800-3-SAMSON (1-800-372-6766) Fax: 631-784-2201 www.samsontech.com...

  • Page 4: Introduction

    Resound HD loudspeakers features heavy-duty, custom designed low frequency drivers. A ten-inch woofer in the Resound HD RS10HD and RS10mHD , a 12-inch for the Resound RS12HD and RS12mHD and 15-inch woofers for the RS15HD, RS15mHD and RS215HD. To handle the high frequency content, the Resound HD series employs a 1.4-inch (34 millimeter) titanium diaphragm high frequency driver...

  • Page 5: Resound Hd Features

    RS1OmHD RS215mHD The Samson Resound HD series two-way loudspeaker systems offer several models to manage a variety of live sound applications. With their high quality components, convenient sized trapezoidal and low profile monitor enclosures, ergonomic carry handles and stand mounts, the Resound HD series system will provide great sound with reliability.

  • Page 6: Resound Hd Components

    Resound HD Components Resound HD FRONT PANEL Wide Dispersion Horn – 1 inch throat, 60 x 90 degree wide dispersion horn provides extensive coverage and linear, off axis response. Titanium Compression Driver – 1.4inch (34mm), Titanium diaphragm with 1 inch opening. Woofer –...

  • Page 7: Controls And Functions

    Connecting the Resound HD Speaker System Choosing the Correct cables The Resound HD series speaker connections are made via the rear panel 1/4-inch and/or Neutrik Speakon® connectors. Standard, unshielded speaker wire, available at your local pro audio or music store, with either 1/4-inch phone or Speakon connectors and wire gauge of 12-14 is recommended.

  • Page 8: Quick Set-Up

    Quick Set-Up In the following pages of this manual, you will find a detailed explanation of system set-ups, but if you just want to get started quickly, you can follow the diagram and steps below to set up a basic stereo PA system. NOTE: Before plugging in and turning on, it is important to remember the Golden Rule of audio …...

  • Page 9: Positioning The Resound Hd

    In many instances when using the Resound HD as a monitor system, you may choose to use an external equalizer like the Samson S Curve 131 to increase the volume and reduce the chance of feedback.

  • Page 10: Setting Up Your Resound Hd

    Setting Up Your Resound HD System...

  • Page 11: Resound Hd Wiring Guide

    Resound HD Wiring Guide The Resound HD provides both Speakon and 1/4” phone connectors for easy interface with industry standard cables. You can use a variety of standard speaker cables that are available “off the shelf” at your local pro-audio or musical instrument retailer.

  • Page 12: Specifications

    Resound HD Specifications 480mm RS215HD 18.9” Power Rating (@ 8Ω): 600 Watts RMS, 1200 PEAK Nominal Impedance: 4 Ohms Frequency Response: 40 Hz – 19 kHz Sensitivity: 99 dB SPL @ 1W/1m MAX SPL: 125dB LF Driver: 2 x 15-inch heavy-duty driver HF Driver: 1-inch exit, 34mm Titanium diaphragm compression driver...
  • Page 13 Resound HD Specifications RS10HD Power Rating (@ 8Ω): 150 Watts RMS, 300 PEAK Nominal Impedance: 8 Ohms 443mm Frequency Range: 60 Hz – 19 kHz 17.44” Sensitivity: 92 dB SPL @ 1W/1m MAX SPL: 116dB LF Driver: 10-inch heavy-duty driver...

  • Page 14: Notes

    Notes...
  • Page 16 Samson Technologies Corp. 45 Gilpin Avenue Hauppauge, New York 11788-8816 Phone: 1-800-3-SAMSON (1-800-372-6766) Fax: 631-784-2201 www.samsontech.com...
