Display Setting - Yaesu SM-5000 - COMPUTER Interface Manual

P I
HASE NVERSION
When the received audio phase is reversed, the SM-5000 gives depth to the audio sound.
1. If needed, press both [ CONTRAST ( + )] and [ CON-
TRAST ( – )] switches to change the adjustment mode to
"Audio Setting".
The Audio Setting window will appear on the display.
Note: Pressing of the [ CONTRAST ( + )] / [ CONTRAST ( – )]
switch will store the last selected "Contrast Setting Mode"
or "Audio Setting Mode" to memory.
2. Press the [ CONTRAST ( + )] switch to toggle the audio
ON ON (reversed phase)" or "OFF ON ON
phase "ON
3. A few seconds after pressing the [ CONTRAST (+)]
switch, the Audio Setting window will close.
A C
DJUSTING THE ONTRAST
You may adjust the contrast for best viewing in sunlight, dusk, or night allowing for best readability.
1. If needed, press both [ CONTRAST ( + )] and [ CON-
TRAST (–)] switches to change the adjustment mode to
"LCD Contrast Setting".
The Contrast window will appear on the display.
Note: Pressing of the [ CONTRAST ( + )] / [ CONTRAST (–)]
switch will store the last selected "Contrast Setting Mode"
or "Audio Setting Mode" to memory.
2. Press the [ CONTRAST ( + )] switch to increase the con-
trast of the display.
3. Press the [ CONTRAST (–)] switch to reduce the contrast
of the display.
4. A few seconds after pressing the [ CONTRAST ( + )] /
[ CONTRAST (–)] switch, the Contrast window will close.
S S D
PECTRUM COPE ISPLAY
You may turn off the Spectrum Scope Display.
1. Press and hold the FT
DX
engage the Scope Menu mode.
The SUB DISPLAY- I window will show the Group name
SCOPE SCOPE), while the SUB DISPLAY- II window will show SCOPE SCOPE
(SCOPE
the Menu item. The SUB DISPLAY- III window shows
the current setting of the currently-selected Menu item.
2. Rotate the ( VFO-A )[ SELECT ] knob to select the Menu
DISPLAY DISPLAY DISPLAY DISPLAY", then rotate the ( VFO-B )[ SELECT ]
item "DISPLAY
OFF". OFF OFF OFF
knob to select "OFF
The Spectrum Scope Display turns off.
3. Press the [ C.S ] key briefly to save the new setting and
exit to normal operation.
To turn the Spectrum Scope Display on, repeat the above pro-
cedure, rotating the ( VFO-B )[ SELECT ] knob to select "ON
as in step "2" above.
A
OFF (normal response)". OFF OFF OFF
D
ISPLAY
"ON/OFF"
5000 [ C.S ] key for 2 seconds to
S
UDIO ETTING
S
ETTING
A :
DVICE
When a contrast level is too high, it is difficult to watch the
"Average" and "Peak hold" indication (See page 3).
ON ON ON"
ON
When the FT
lumination level of the SM-5000 will also be reduced.
The amount of brightness may be set via FT
Menu item "011 DISP DIM ELCD".
-7-
[ CONTRAST (–)] Switch
[ CONTRAST (–)] Switch
[ C.S ] Switch ( VFO-A )[ SELECT ] Knob
( VFO-B )[ SELECT ] Knob
D D
ISPLAY IMMER
5000 [ DIM ] button is pressed, the il-
DX
[ CONTRAST ( + )] Switch
[ CONTRAST (+)] Switch
5000
DX
