Welcome!
This owners manual is written in easy english and
uses a lot of drawings to simply the installation and
use of the above amplifiers.
Your DLS amplifiers must be installed correctly in
order to work well. This manual will show you how
to install the amplifier like a pro. Please read the
entire manual before beginning the installation.
Install the amplifier yourself if you feel confident
with our instructions and if you have the proper tools.
However if you feel unsure, turn over the installation
job to someone better suited to it.
Warranty Service
This amplifier is covered by warranty, depending on
the conditions in the country where it is sold. If the
amplifier is returned for service, please include the
original dated receipt with the product.
Technical Assistance
For technical assistance ask the shop where the
product was sold or the distributor in your very coun-
try. Information can also be found on our WEB-site
www.xprogram.com
We follow a policy of continuous advancement in
development. For this reason all or part of specifica-
tions & designs may be changed without prior notice.
DECLARATION OF CONFORMITY
DLS amplifiers for vehicles are manufactured in
accordance with the EU directive EEC 95/54 (72/245/
EEC) and are marked with the approval number.
They are also marked in accordance with the WEEE-
directive 2002/96/EC.
The products are also produced in accordance with
the EU RoHS directive 2002/95/EC.
How to install and operate the
DLS amplifier models
XM20
XM40
Contents
Features...............................................
Installation............................................
Routing Wires........................................
Tools and materials needed......................
Power and remote wiring............................. 3-4
Low & High level input wiring ......................
Input level control, BASS EQ.......................
Features on each model .............................
XM20 speaker wiring:
Front speakers........................................
Subwoofer.............................................
Four speakers........................................
Two subwoofers ........................................
Testing................................................
Troubleshooting....................................
Professional tips...................................
Specifications.......................................
This product must be returned to the
separate collection system for electronic
products. Do not dispose this product
together with general household waste.
DLS amplifiers are designed and engineered by:
DLS Svenska AB
P.O. Box 13029 - SE-40251 Göteborg - Sweden
Tel: +46 31 840060 - Fax: +46 31 844021
E-mail: info@dls.se
www.dls.se
2
2
2
3
4
5
5
6
6
7
7
8
8
9
10
11
