STEP 7: Attaching the doubling plates
Place the appropriately sized doubling plates on the locations
marked in step 6.
Temporarily holding the protective cage leg in place, check that
the release mechanism operates freely.
There must always be enough space between a protective cage
and its respective sensor adapter so that in the event it becomes
bent, the sensor may still be removed.
