S-band HSC SRT Adapter Box Installation Guide Addendum ENGLISH navico-commercial.com...
Page 2
This is a dedicated instruction to carry out an Argus S-band HSC installation using a standard cable and an additional S-band HSC SRT adapter box. To obtain the S-band in HSC, install one module SRT adapter box, part number 000-13194- 001, unit type SRTAB-001.
Page 3
Green 2 x 0.35 mm shielded twisted pair Black 2 x 0.35 mm shielded twisted pair Black 0.35 mm single core White 0.35 mm single core Blue 0.35 mm single core S-band HSC SRT Adapter Box | Installation Guide Addendum...
Phillips screwdriver • Scissors and tongs AMP mod2 Wiring procedure For installation you need 50 cm of free cable. “C” cable to SRT up mast Cable from core unit “B” S-band pedestal S-band HSC SRT Adapter Box | Installation Guide Addendum...
Page 5
Fig. 1 Fig. 2 Fig. 3 Open the SRT box. Check the cable length. Prepare the cable. Fig. 4 Fig. 5 Fig. 6 Min 40 cm, Max 70 cm. Shield connection. S-band HSC SRT Adapter Box | Installation Guide Addendum...
Page 6
Open the cable gland (5.5 mm). Use the 10 mm flat spanner. Insert cable C. Fig. 13 Fig. 14 Fig. 15 Close with cable B and tighten. Insert all cables into the slot. Close and tighten. S-band HSC SRT Adapter Box | Installation Guide Addendum...
Page 7
Switch on the unit’s main switch. Connect a test lead to relay pin 2T1. GND must be present + 48 VDC +- 15%. Close the box and test the S-band antenna at HSC speed. S-band HSC SRT Adapter Box | Installation Guide Addendum...
