4. Adjusting the head support / adjusting the seat to the child's size
4.12
When does the shortened belt
system need to be returned to
its lengthened setting?
If, after releasing the child seat
belt by means of the central
adjuster, it does not pull forwards
sufficiently to allow the belt
system to be closed, then the
belt system needs to be
lengthened.
To do this proceed as follows:
4.13
0104-04
Remove the seat shell from the
base unit and lay the shell upside
down on a clean surface.
Release the elastic tapes on the
cover and pull the cover back a
little. Lever out the metal clasps
secured on the side of the shell
and push them back through their
slots.
4.14
0053-06
Now press the metal clasps from
the outside into the recess. The
clip must engage with an audible
"click".
Both sides must be adjusted
equally!
0254-01
0054-06
click
