Summarization of Contents
Employer Responsibilities
Safety Instructions First Use
Read and understand safety instructions before operating the tool.
Tool Use
Safe Tool Direction and Air Connection
Keep tool pointed away from yourself and others; connect air to tool.
Loading SFW08/SJ10
Load SFW08/SJ10 by pushing latch and sliding rail open.
Loading SFW10/SFT10
Load SFW10/SFT10 by depressing latch and sliding rail open.
Loading Staples into Magazine
Place staples into magazine; use genuine SENCO staples; do not load with trigger depressed.
Securing Magazine Rail
Push magazine rail forward until it latches securely.
Loading DFP/F50
Load DFP/F50 by depressing staple door release and pulling door back.
Loading DFP/F50 Staples
Load DFP/F50 staples onto rail; use genuine SENCO staples; do not load with trigger depressed.
Releasing DFP/F50 Staple Door
Release DFP/F50 staple door and slide it forward.
Loading F75
Load F75 by pulling staple door back into "locked" position.
Loading F75 Staples
Load F75 staples onto rail; use genuine SENCO staples; do not load with trigger depressed.
Releasing F75 Staple Door
Release F75 staple door and slide it forward.
Tool Condition Warning
Do not use a tool that leaks air or requires repair for safe operation.
Driving Fasteners SJ10/SFW10/SFW08/SFT10
Position tool against work surface and pull trigger to drive fasteners.
Driving Fasteners DFP/F50/F75
Insert material, pull and release trigger to drive fasteners on DFP/F50/F75.
Staple Jam Procedure
Disconnect air supply if a staple jam occurs.
Removing Staples
Remove staples from the tool.
Removing Jammed Fastener
Remove jammed fastener from the tool.
Removing Staples DFP/F50/F75
Pull DFP/F50/F75 staple door back to "locked" and remove staples.
Using Chisel for Staple Removal
Use chisel to push staple towards guide body bottom; grasp and remove with pliers.
Reconnecting Air and Replacing Fasteners
Connect air supply, replace fasteners, release staple door, and slide forward.
SFT10 Cycle Speed Adjustment
Adjust cycle speed on SFT10 by turning adjustment knob.
SFT10 Single Fastener Drive
Drive single fastener on SFT10 by releasing trigger, holding lever, then pulling trigger.
SENCO Tool Accessories
Available Accessories List
List of available SENCO tool accessories including compressors, hose, couplers, fittings, safety glasses, gauges, lubricants, regulators, filters.
Maintenance and Care
Initial Safety and Manual Review
Read and understand "SAFETY INSTRUCTIONS" manual before using tool.
Screw Tightness
Keep all screws tight to ensure safe operation and prevent parts breakage.
Trigger Movement Inspection
Perform daily inspection of trigger movement with tool disconnected; do not use if it sticks or binds.
Lubrication Requirements
Routine lubrication is not necessary for SJ10; do not oil. Use SENCO pneumatic oil for other models.
Daily Cleaning and Inspection
Wipe tool clean daily and inspect for wear; use non-flammable cleaning solutions only if necessary.
Troubleshooting Guide
Repair Warning
Repairs should only be performed by trained personnel; contact SENCO for information.
Air Leak Near Top / Sluggish Operation
Verify air supply, tighten screws, or install Parts Kit A for air leaks near the top.
Air Leak Near Bottom / Poor Return
Tighten screws, clean tool, or install Parts Kit B for air leaks near bottom or poor return.
Broken Driver / Weak Drive
Verify air supply or install Parts Kit C for broken driver or weak drive issues.
Poor Feed / Tool Jamming
Clean tool, lubricate magazine, or install Parts Kit D for poor feed or jamming.
Other Problems
For other problems not listed, contact SENCO.
Optional Tool Configurations
Double Length Magazine Assembly
Increases staple loading capacity; requires two guide body screws and one handle screw removal.
Staple Conversion
Enables the tool to fire shorter legged staples.
Remote Fire Fitting
For remote activation; requires Normally Closed (N.C.) valve.
Sencomatic Conversion Kit
Sencomatic Conversion Kit Details
Includes parts to convert standard tool to Sencomatic; magazine/piston not included.
Piston/Driver Assembly Specifications
Details piston/driver assembly parts, staple codes, and countersink depths.
Picture Frame Attachment
Accessory for picture frame assembly.
Technical Specifications
SFW10 Specifications
Operating pressure, air consumption, air inlet, speed, weight, staple capacity, and dimensions.
SFW08 Specifications
Operating pressure, air consumption, air inlet, speed, weight, staple capacity, and dimensions.
SJ10 Specifications
Operating pressure, air consumption, air inlet, speed, weight, staple capacity, and dimensions.
DFP Specifications
Operating pressure, air consumption, air inlet, speed, weight, staple capacity, and dimensions.
F50/F75 Specifications
Operating pressure, air consumption, air inlet, speed, weight, staple capacity, and dimensions.
SFT10 Specifications
Operating pressure, air consumption, air inlet, speed, weight, staple capacity, and dimensions.
Staple Specifications
DFP/F50/F75 Staple Dimensions
Diagram and code specifications for DFP/F50/F75 staples.
Staple Dimensions SFW08/SFW10/SFT10
SFW08/SFW10/SFT10 Staple Codes
Diagram and code specifications for SFW08/SFW10/SFT10 staples.
SFT10 Staple Specifications
Diagram and code specifications for SFT10 staples.
Staple Dimensions SFW10/SJ10
SFW10/SJ10 Staple Codes
Diagram and code specifications for SFW10/SJ10 staples.
Senco Tool & Parts Warranty
Warranty Coverage and Conditions
One-year warranty for repair/replacement of defective parts, subject to conditions.
Warranty Exclusions
Excludes implied warranties; limits liability to price of tool; excludes consequential damages.
Natural Disaster Replacement
Tool replacement for Acts of God if warranty registered and proof submitted.
