Delta KHB1748HHT Specification Sheet

Bearing Type
*
Ball Bearings
Material
*
Impeller : Plastic (UL 94V-0)
Pillow : Die-Cast Aluminum
Lead Wires :
*
UL 1430 AWG #22 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 670g (23.63 oz)
*
MODEL
PART NO. FUNCTION
KHB1748MT -R00/ -F00
KHB1748HT -R00/ -F00
KHB1748HHT -R00/ -F00
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
KHB
DIMENSIONS DRAWING
P & Q CURVE
2.4
60.0
2.0
50.0
1.6
40.0
1.2
30.0
0.8
20.0
0.4 10.0
0 0
0
0
Operating
Rated Input
Voltage
Current
Voltage
Range
VDC VDC Amp
48 32.0 to 80.0 0.36
48 32.0 to 80.0 0.57
48 32.0 to 80.0 0.73
175 x 69 MM SERIES
(AT RATED VOLTAGE)
KHB1748XT
HH
H
M
3
2.0 4.0 6.0 8.0 10.0 (M /MIN)
80.0 160.0 240.0 320.0 (CFM)
Air Flow
Input
Speed
Power
3
Watt R.P.M. m /min
17.28 2100 5.746
27.36 2400 6.735
35.04 2700 7.132
134
MOUNTING PANEL CUTOUT
Maximum Maximum
Air Flow Air Pressure
CFM mmH O IN H O
2
202.92 17.59 0.693
237.85 23.34 0.919
251.87 30.70 1.209
http://www.deltaww.com
Noise
dB-A
2
55.0
59.0
62.5
