Baxton Studio Kristy BBT5197 Assembly Instructions

MODEL : BBT5197 Bench
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
STEP 1
B
ASSEMBLY INSTRUCTIONS
2
4
3
1
4
3
A
PART LIST
ITEM DESCRIPTION
A
BENCH
B
LEG
STEP 2
5
PART LIST
QTY ITEM DESCRIPTION
1
JCBC BOLT M6 x 80mm
1 PC
2
JCBC BOLT M6 x 45mm
2 PCS
3
M6 FLAT WASHER
4
M6 SPRING WASHER
5
M4 ALLEN LEY (BALL SHAPE) M4 ALLEN LEY
QTY
8 PCS
4 PCS
12 PCS
12 PCS
1 PC
