Baxton Studio BBT5218 Assembly Instructions

MODEL : BBT5218 Bar Bench MODEL : BBT5218 BAR BENCH
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
STEP 1
6
B
3
B
A
ASSEMBLY INSTRUCTIONS
STEP 2
A
1
C
D
4
E
C
2
3
4
PART LIST
ITEM DESCRIPTION
A CHAIR FRAME
B BOX SEAT
C CHAIR LEG
D SIDE STRETCHER
E FRONT STRETCHER
STEP 3
5
C
4 D
6
PART LIST
ITEM DESCRIPTION
QTY
1 JCBC Bolt M6 x 50mm
1 PC
2 JCBC Bolt M6 x 60mm
2 PCS
3 WOOD SCREW M4 x 32mm
4 PCS
4 M6 FLAT WASHER
2 PCS
5 M6 SPRING WASHER
2 PCS
M4 ALLEN KEY (BALL SHAPE)
6
QTY
4pcs
8pcs
12pcs
12pcs
8pcs
1pc
