Baxton Studio BBT5390-CC Assembly Instructions

MODEL : BBT5390 - CC
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
Tool needed : (not provided).
Screwdriver

STEP 1

ASSEMBLY INSTRUCTIONS
ITEM
A
B
C
D

STEP 2

B
A

PART LIST

ITEM
QTY
DESCRIPTION
1 JCBC Bolt M6 x 45mm
CHAIR BACK 1 PC
2 JCBC Bolt M6 x 60mm
CUSHION SEAT FRAME 1 PC
3 JCBC Bolt M6 x 80mm
ARM (L) 1 PC
4 JCBC Bolt M6 x 90mm
ARM (R)
1 PC
5 M6 FLAT WASHER
6 M6 SPRING WASHER
7 WOOD BUTTON DIA 13.5mm
M4 ALLEN KEY (BALL SHAPE)
8
STEP 2.1
STEP 2.2
8
1
6
5
Don't screw tied
Don't screw tied
1 OF 2

HARDWARE LIST

DESCRIPTION QTY
4 PCS
4 PCS
2 PCS
2 PCS
10 PCS
12 PCS
2 PCS
1 PC
8
3
4
6
5
