MODEL : BBT5381.12 - DC
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
Tool needed : Screwdriver (not provided).
x4
3
1
2
B
A
ITEM
DESCRIPTION
QTY
A
CHAIR
1 PC
B
CHAIR LEG
1 PC
HARDWARE LIST
ITEM
DESCRIPTION
1
JCBC BOLT M6 x 60mm
2
M6 SPRING
3
M4 ALLEN KEY (BALL SHAPE)
1 OF 1
QTY
4 PCS
4 PCS
1 PC
