Alamo A84B Operator's Manual

Alamo industrial rotary mower operator's manual

Table of Contents

Quick Links

Download this manual

Published 03/07

This Operator's Manual is an integral part of the safe operation of this machine and must

be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety

and Operation Instructions contained in this manual before operating the equipment. C01-

Cover

ALAMO INDUSTRIAL

1502 E. Walnut

Seguin, Texas 78155

830-372-3551

Email: parts@alamo-industrial.com

OPERATOR'S MANUAL

A84B

ROTARY MOWER

Part No. 00760989C

$0.00

Table of Contents

Summary of Contents for Alamo A84B

Page 1: Rotary Mower
READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. C01- Cover ALAMO INDUSTRIAL 1502 E. Walnut Seguin, Texas 78155 830-372-3551 Email: parts@alamo-industrial.com ® ©2007 Alamo Group Inc. A84B ROTARY MOWER Part No. 00760989C $0.00...
Page 2 To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of acci- dents.
Page 3 In order to reduce accidents and enhance the safe operation of mowers, Alamo Industrial, in cooperation with other industry manufacturers has developed the AEM/FEMA Industrial and Agricultural Mower Safety Practices video and guide book. The video will familiarize and instruct mower-tractor operators in safe practices when using industrial and agricultural mowing equipment.
Page 4 Alamo Industrial Division is willing to provide one (1) AEM Mower Safety Practices Video Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video DVD Format – AEM/FEMA Mower Operator Safety Video Mower Operator’s Manual AEM Mower Operator’s Safety Manual...
Page 5: Table Of Contents
Table of Contents SAFETY SECTION ... 1-1 General Safety Instructions and Practices ... 1-2 Operator Safety Instructions and Practices ... 1-3 Equipment Operation Safety Instructions and Practices ... 1-5 Connecting or Disconnecting Implement Safety Instructions and Practices ... 1-11 Transporting Safety Instructions and Practices ... 1-11 Maintenance and Service Safety Instructions and Practices ...
Page 6 STARTING THE TRACTOR ... 4-10 CONNECTING THE MOWER TO THE TRACTOR ... 4-10 Connecting the Mower-Lift Type ... 4-11 Connecting the Mower-Pull Type ... 4-12 Safety Chains ... 4-13 SETTING THE MOWER ... 4-13 Setting Mower Height- Lift Type ... 4-13 Setting Mowing Height-Pull Type ...
Page 8: General Safety Instructions And Practices
Safety Messages. Always use good common sense to avoid hazards. Si no lee ingles, pida ayuda a alguien que si lo lea para que le traduzca las medidas de seguridad. A84B 03/07 © 2007 Alamo Group Inc. SAFETY (SG-2) (SG-3)
Page 9: Operator Safety Instructions And Practices
A84B 03/07 © 2007 Alamo Group Inc. SAFETY “Wait a minute...Save a life!” Never allow inexperienced or...
Page 10 Take scheduled work breaks to help prevent these potentially impaired operating conditions. Never operate the Implement and Tractor in a fatigued or bored mental state which impairs proper and safe operation. (SG-32) A84B 03/07 © 2007 Alamo Group Inc. SAFETY EXPOSURE LOUD NOISE...
Page 11: Equipment Operation Safety Instructions And Practices
A-Frame. Lower the implement carefully to the ground. Do not put hands or feet under lifted components. A84B 03/07 © 2007 Alamo Group Inc. SAFETY (SG-33)
Page 12 (SG-9) Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. A84B 03/07 © 2007 Alamo Group Inc. SAFETY Be careful when operating or transporting this (SBH-6) Shut down PTO and the Tractor...
Page 13 Operate the Tractor and/or Implement controls only while properly seated in the Tractor seat with the seat belt securely fastened around you. Implement may cause serious injury or death. A84B 03/07 © 2007 Alamo Group Inc. SAFETY (SG-13) (SG-23) Inadvertent movement of the Tractor or...
Page 14 Stop mowing immediately if blades strike a foreign object. Repair all damage and make certain rotor or blade carrier is balanced before resuming mowing. (SGM-5) A84B 03/07 © 2007 Alamo Group Inc. SAFETY (SG-40) (SGM-4) Inspect the area before...
Page 15 Mower with the wrong size Tractor can cause Mower component damage and equipment failure resulting in possible serious injury or death. A84B 03/07 © 2007 Alamo Group Inc. SAFETY (SGM-6) Check to make sure there are no...
Page 16 Raising the Mower deck exposes the Cutting Blades which creates a potentially serious hazard and could cause serious injury or even death from objects thrown from the Blades. A84B 03/07 © 2007 Alamo Group Inc. SAFETY (SGM-15) (SPU-1)
Page 17: Connecting Or Disconnecting Implement Safety Instructions And Practices
Dropping implement in transport can cause serious damage to the tractor and/or Implement and possibly cause the operator or others to be injured or killed. A84B 03/07 © 2007 Alamo Group Inc. SAFETY (S3PT-16) Safety Section 1-11...
Page 18 Make certain that at least 20% of the tractor’s weight is on the front wheels to maintain safe steerage. Slow down on rough or uneven surfaces. (STI-1) A84B 03/07 © 2007 Alamo Group Inc. SAFETY (SG-19) Safety Section 1-12 (S3PT-20)
Page 19: Maintenance And Service Safety Instructions And Practices
(SG-5) Do not modify or alter this Implement. Implement, any of its components or any Implement function. A84B 03/07 © 2007 Alamo Group Inc. SAFETY Never tow the Implement at speeds over 20 (STI-10) (S3PT-8)
Page 20 Missing, broken, or worn items must be replaced at once to reduce the possibility of injury or death from thrown objects, entanglement, or blade contact. A84B 03/07 © 2007 Alamo Group Inc. SAFETY (SG-14) Make sure the tractor engine is off, the...
Page 21: Concluding Safety Instructions And Practices
See your Authorized Dealer for proper repairs. Alamo Industrial mowers use balanced and matched system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Alamo Industrial specifications.
Page 22: Decal Location
Decal Location NOTE: Alamo supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Alamo cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 23 02959924 ( ) Quantities for Pull Type Only ** 540 or 1000 RPM units only. Select correct one. * Furnished by tractor manufacturer *** Supplied on Driveline A84B 03/07 © 2007 Alamo Group Inc. SAFETY TYPE PELIGRO DANGER 1*** DANGER...
Page 24: Decal Description
DANGER! Guard Missing, Do Not Operate. If you see this decal, Do Not Operate the mower until the shield has been replaced. P/N 00756004 DANGER! Rotating Driveline Keep Away, Contact can cause death. P/N 00756005 A84B 03/07 © 2007 Alamo Group Inc. SAFETY Safety Section 1-18...
Page 25 P/N 00769737 DANGER! Make certain that drivelines are correct length and are securely attached. P/N 00756494 A84B 03/07 © 2007 Alamo Group Inc. SAFETY Safety Section 1-19...
Page 26 IMPORTANT - Use only Genuine Alamo Industrial replacement parts. P/N 02925100 PELIGRO! Spanish Translation for Driveline Safety P/N 00773723 Slow Moving Vehicle Decal. Keep SMV reflector clean and visible. DO NOT transport or operate without the SMV. P/N 03200347 IMPORTANT! - Required for Equal-Angle Driveline Unit.
Page 27 P/N D114 WARNING! Avoid Bodily Injury, Use 540RPM PTO Speed Only. P/N D103 Operator's Manual (with repair parts) and warranty was attached to this implement during final inspection. P/N 00763977 A84B 03/07 © 2007 Alamo Group Inc. SAFETY Safety Section 1-21...
Page 28 NAME LOGO - Alamo Industrial P/N 02960766 WARNING! DO NOT transport at speeds higher than 20 mph. Only transport behind a sized and equipped tractor. P/N 00777394 Name LOGO - Alamo Industrial P/N 00757139 NAME LOGO - A84B P/N 00769874 A84B 03/07 ©...
Page 29 Amber Reflector. Keep reflectors clean and visible. P/N 1458393 Read Operator’s Manual! The operator’s manual is located inside this canister. If the manual is missing order one from your dealer. P/N 00776031 A84B 03/07 Safety Section 1-23 © 2007 Alamo Group Inc.
Page 30: Federal Laws And Regulations
(Refer to U.S. Dept. of Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.) A84B 03/07 © 2007 Alamo Group Inc. SAFETY This section is not intended as a legal...
Page 76 Indicates an imminently hazardous situation that, if not avoided, MAY result in MINOR INJURY. Identifies special instructions or procedures that, if not strictly observed, could result in damage to, or destruction of the machine, attachments or the environment. A84B 03/07 © 2007 Alamo Group Inc. INTRODUCTION Introduction Section 2-2...
Page 77 Slow down on hills, rough terrain, and curves. The front, rear, left, and right are determined by the normal direction of travel, the same as driving an automobile A84B 03/07 © 2007 Alamo Group Inc. INTRODUCTION The Mower manufacturer strongly Introduction Section 2-3...
Page 78: Attention Owner/Operator
NOTE: Warranties are honored only if completed “Owner Registration and Warranty” forms are received by Alamo Group within thirty days of delivery of the implement. 3. Record the Blade Model and Serial Numbers on the Warranty page at the front of the Operator’s Manual.
Page 80: Standard A-Frame Assembly(Figure Asm-R-0123)
5/8 x 1-1/2 bolts (7) and locknuts (8). Tighten all bolts securely Attach the Cat. II Hitch pins (10) to the top front holes in the lift lugs and retain with pins (11). A84B 03/07 Assembly Section 3-2 © 2007 Alamo Group Inc.
Page 81: Optional A-Frame Assembly (Figure Asm-R-0124)
3/4 x 1-1/2 (17) and locknut (13). 5. Install Brace supports (4) to the rear lugs on the Main Frame with bolts 3/4 x 2 (10), flatwashers (14), bushings (6) and locknuts (13). A84B 03/07 © 2007 Alamo Group Inc. ASSEMBLY Assembly Section 3-3...
Page 82: Single Tail Wheel Assembly - Lift Type Figure Asm-R-0125
Install bolts 11) & nuts (12) on top and bottom of tailwheel beam. Insert through pair of holes which will give approximate desired cutting height. Tighten all bolts per Torque Chart. A84B 03/07 Assembly Section 3-4 © 2007 Alamo Group Inc.
Page 83: Dual Tail Wheel Assembly - Lift Type - Figure Asmp-R-0022
Install bolts (10) & nuts (11 - not shown) on top and bottom of tailwheel beam. Insert through pair of holes which will give approximate desired cutting height. Tighten all bolts.. A84B 03/07 Assembly Section 3-5 © 2007 Alamo Group Inc.
Page 84: Pull-Type
Attach the two level-lift control rods to the lower lugs on tongue and to lugs on the rear axle tube using pins, washers and cotter pins. Note: The adjusting nuts on control rods should be to rear of machine. Figure Asm- R-0037. A84B 03/07 © 2007 Alamo Group Inc. ASSEMBLY Assembly Section 3-6...
Page 85: Hydraulic Or Manual Lift
Install the Wheels on the Wheel Hubs. Note: If Laminated Tires are used, place the flat side of the Lug Nut against the Wheel Figure Asm-R-0127. Note direction of travel and curvature of rubber segments in tire and install as shown in Figure Asm-R-0127. A84B 03/07 Assembly Section 3-7 © 2007 Alamo Group Inc.
Page 86: Front And Rear Deflectors (Standard Equipment) And Chainguards (Optional Equipment At Extra Cost) (Figure Asm-R-0128)
Mounting Plates with 1/2" x 1-1/2" bolts(8) Flatwashers(9) and Locknuts (10). Fasten Side Rear Chain Guard (11) to Chain Guard Mounting Plates (1&2) with 1/2" x 1-1/4" bolts (12) Flatwashers (13) and Locknuts (14). A84B 03/07 © 2007 Alamo Group Inc. ASSEMBLY Assembly Section 3-8...
Page 87: Chain Guard (Extra Equipment)
Guards attach with 1/2" x 3" bolts (10), Flatwashers (11), Spacers (12) and Locknuts (13). Fasten Side Rear Chain Guard (14) to Chain Guard Mounting Plates (1&2) with 1/2" x 1-1/4" bolts (15) Flatwashers (16) and Locknuts (17). A84B 03/07 © 2007 Alamo Group Inc. ASSEMBLY Assembly Section 3-9...
Page 88: Driveline Attachment (Figure Asm-R-0129)
Remove top two bolts in front cover plate in gearbox. Attach shield assembly using 2 longer bolts (5) and washers (6) supplied. Spacers (4) must be installed between gearbox and shield bracket. Install bolts with lockwashers and tighten. Install wing nut (2) to retain shield. A84B 03/07 © 2007 Alamo Group Inc. ASSEMBLY Assembly Section 3-10...
Page 89: Check Chains (Extra Equipment) For Lift Models (Figure Asm-R-0131)
For additional safety in transport, raise mower as high as possible without having driveline hit deck and shorten check chains as much as possible to prevent inadvertent falling in transport. A84B 03/07 © 2007 Alamo Group Inc. ASSEMBLY Assembly Section 3-11...
Page 90: Jackshaft Bearing Support Assembly (Figure -Pull Type)
Jackshaft through bearing (4) slide spacer (7) on Jackshaft (NOTE: Spacer goes between bearing and Quick Disconnect Yoke.) See parts pages for Jackshaft Bearing Support prior to Serial # 10705 NOTE: ALL Yokes must be set as shown for proper phasing. A84B 03/07 Assembly Section 3-12 © 2007 Alamo Group Inc.
Page 92: Operation Instructions
Proper operation of the A84B mower, as detailed in this manual, will help ensure years of safe and satisfactory use of the mower.
Page 93: Standard Equipment And Specifications
Mower with the wrong size Tractor can cause Mower component damage and equipment failure resulting in possible serious injury or death. A84B 03/07 © 2007 Alamo Group Inc. OPERATION A84B 30 HP Min. (Pull) 60 HP (Lift) 2”...
Page 94: Operator Requirements
Serious injury or death to the operator or others could result if the operator is under the influence of drugs or alcohol. A84B 03/07 © 2007 Alamo Group Inc. OPERATION Drugs and alcohol will affect an operator’s...
Page 95: Tractor Requirements
(ROPS). Always wear seat belts. Serious injury or even death could result from falling off the tractor--particularly during a turnover when the operator could be pinned under the ROPS. A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SG-7) Operation Section 4-5...
Page 96: Tractor Safety Devices
The power required to operate a mower is determined by the tractor PTO horsepower. For most mowing conditions, the A84B mower requires a tractor with at least 60 HP for a lift unit and 30 HP for a pull type.
Page 97: Drawbar-Pull Type Mower
Lift arm stabilizers must be used with this type of drawbar to prevent the mower from swaying from side to side. OPS-R- 0061 A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-7...
Page 98: Front End Weight
OPS-U- 0007 Do not mount the Tractor while the tractor is moving. Mount the Tractor only when the Tractor and all moving parts are completely stopped. A84B 03/07 © 2007 Alamo Group Inc. OPERATION (S3PT-16) Operation Section 4-8...
Page 99: Boarding The Tractor
Never dismount a Tractor that is moving or while the engine is running. Operate the Tractor controls from the tractor seat only. (SG-9) A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SG-10) Operation Section 4-9 (SG-11)
Page 100: Starting The Tractor
Use extreme caution when connecting the mower to the tractor. The mower should be securely resting at ground level or setting on blocks. Keep hands and feet from under the mower deck and clear of pinch points between the tractor hitch arms and mower pins. OPS-R-0001 A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SG-23) (SG-13)
Page 101: Connecting The Mower-Lift Type
Adjust any lower link check chains, guide blocks, or sway blocks to prevent the mower from swaying side to side and possible con- tact with tractor rear tires. A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-11...
Page 102: Connecting The Mower-Pull Type
Lower the jack until the tongue is completely supported by the drawbar. Remove jack from the tongue and place on storage bracket of mower main frame. A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-12...
Page 103: Safety Chains
Shut down the tractor and remove the key. Level the mower deck front to rear by extending or retracting the 3-point top link. A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SG-14) Operation Section 4-13...
Page 104 3-Point lift maintaining a set height or when a constant preadjusted cut height is required. See Check Chains in the Assembly Section for this accessory. A84B 03/07 © 2007 Alamo Group Inc. OPERATION Align Operation Section 4-14...
Page 105: Setting Mowing Height-Pull Type
In addition, a more even distribution of the clippings from the rear of the mower will be achieved with this angle A84B 03/07 © 2007 Alamo Group Inc. OPERATION . OPS-R-0002_D...
Page 106: Driveline Attachment
At its shortest length, there must be at least a 1” clearance between each profile end and opposite profile universal joint. At its farthest operating extension, a minimum profile engagement of 12” must be maintained. A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-16 (S3PT-17)
Page 107 NOTE: When raising the mower, at least 1” clearnace must be maintained between the driveline and the mower deck. If necessary, place an upper lift stop on the 3-point hitch control lever to limit the height the mower can be raised. OPS-R-0005_C A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-17...
Page 108: Pre-Operation Inspection And Service
Make sure all pins have cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order. A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SG-14) (SG-21)
Page 109: Tractor Pre-Operation Inspection/Service
Ensure the manual canister is secured to the equipment with the operator’s manual inside. • Ensure all decals are in place and legible. Replace missing, damaged, and illegible decals. OPS-U- 0011 A84B 03/07 © 2007 Alamo Group Inc. OPERATION The following Maintain these Operation Section 4-19...
Page 110 Missing, broken, or worn items must be replaced at once to reduce the possibility of injury or death from thrown objects, entanglement, or blade contact. A84B 03/07 © 2007 Alamo Group Inc. OPERATION All safety devices should be inspected (SGM-3)
Page 111 • Ensure the gearbox vent is in place and free from clogs. OPS-R-0040 A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-21...
Page 112: Cutting Component Inspection
• Ensure carrier hub nut is tightened with the cotter pin inserted and spread. OPS-R-0041_A 9.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: OPS-U-0031 A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-22...
Page 113 Failure to replace abnormally worn blades may lead to catastrophic failure of the blades and ejection of the broken part with tremendous force which may cause serious bodily injury or death. OPS-U-0032 A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-23...
Page 114 Blade bolts are tight Wheel lug nuts are tight Transport locks are in good condition Operator’s Signature: DO NOT OPERATE an UNSAFE TRACTOR or MOWER A84B 03/07 © 2007 Alamo Group Inc. OPERATION Make ____________________ ________________ Shift Condition at Start of Shift...
Page 115 The engine coolant fluid level is full The radiator is free of debris The air filter is in good condition Operator’s Signature: DO NOT OPERATE an UNSAFE TRACTOR or MOWER A84B 03/07 © 2007 Alamo Group Inc. OPERATION Make ____________________ ________________ Shift Condition at...
Page 116: Driving The Tractor And Implement
When operating in traffic always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SG-23) (SG-19)
Page 117: Starting The Tractor
When operating in traffic, always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-27...
Page 118: Raising The Mower
Use extreme caution when operating on steep slopes. Keep the tractor in a low gear when going downhill. DO NOT coast or free-wheel downhill. OPS-R-0019 A84B 03/07 © 2007 Alamo Group Inc. OPERATION When OPS-R-0042 Determine the Operation Section 4-28...
Page 119: Crossing Ditches And Steep Inclines
When confronted with an incline or ditch, do not approach from an angle which is perpendicular or straight on as damage to or over-collapse of the driveline may occur. OPS-R-0021_A A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-29...
Page 120: Operating The Tractor And Implement
Stop mowing immediately if blades strike a foreign object. Repair all damage and make certain rotor or blade carrier is balanced before resuming mowing. (SGM-5) A84B 03/07 © 2007 Alamo Group Inc. OPERATION Inspect the area before Operation Section 4-30...
Page 121: Foreign Debris Hazards
If a bystander comes within 300 feet of the tractor while the mower is being operated, stop the tractor at once, idle the engine and disengage the PTO. Do not engage the PTO again until all bystanders are well past the 300 foot distance. OPS-R-0024 A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SGM-6) Remove all...
Page 122: Engaging The Power Take Off (Pto)
Do not put hands or feet under mower decks. Blade Contact can result in serious injury or even death. Stay away until all motion has stopped and the decks are securely blocked up. A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SRM-1) (SRM-7)
Page 123: Pto Rpm And Ground Speed
When mowing in reverse, operate the tractor and mower at a much reduced ground speed to ensure control is maintained of the tractor and cutter. A84B 03/07 © 2007 Alamo Group Inc. OPERATION OPS-R-0026_H Operation Section 4-33...
Page 124 12” from ground level, disengage the tractor PTO and wait for all mower rotation to come to a complete stop before proceeding to raise the mower. OPS-R-0027_B A84B 03/07 © 2007 Alamo Group Inc. OPERATION Never raise the Operation Section 4-34 (SGM-1)
Page 125 90 degree angle to the first pass to reduce streaking for a more uniform cut. OPS-R-0044 A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SRM-7) If possible, Operation Section 4-35...
Page 126: Shutting Down The Implement
Use extreme care to keep feet and hands from under the mower and clear of any pinch points caused by the tractor hitch arms and mower pins. OPS-R-0030_A A84B 03/07 Operation Section 4-36 © 2007 Alamo Group Inc.
Page 127 Do not let the driveline fall into mud or dirt, which can contaminate the bearing and shorten the life of the driveline. OPS-R-0031_A A84B 03/07 © 2007 Alamo Group Inc. OPERATION Lower the Operation Section 4-37...
Page 128: Mower Storage
By using good judgement and following safe transport procedures, the possibility of accidents while moving between locations can be substantially minimized. OPS-U- 0017 A84B 03/07 © 2007 Alamo Group Inc. OPERATION (SG-10) Operation Section 4-38...
Page 129: Transporting On Public Roadways
Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in such a way as to be clearly visible and legible. When transporting the Equipment use the Tractor flashing warning lights and follow all local traffic regulations. A84B 03/07 © 2007 Alamo Group Inc. OPERATION NOTE: When...
Page 130 Use caution and reduce speed if other vehicles or pedestrians are in the area. OPS- U- 0022 A84B 03/07 © 2007 Alamo Group Inc. OPERATION emblem roads, have Operation Section 4-40...
Page 131: Hauling The Tractor And Implement
OPS-U- 0025 A84B 03/07 © 2007 Alamo Group Inc. OPERATION Operation Section 4-41...
Page 132 If during transport a hard braking, sharp turning, or swerving action was performed, stop at the next safe location to inspect the security of the load. OPS-U- 0026 A84B 03/07 Operation Section 4-42 © 2007 Alamo Group Inc.
Page 133: Troubleshooting Guide
Replace blade bolts. Replace Blades. Replace Blades; with hardened, high-quality, Alamo Industrial Blades. from the manufacturer. Tighten Bolts to 300 ft./lbs. Replace Blade Carrier. Replace Locknut. See your local Alamo Industrial Dealer. Run in or change Gears. Replace Bearing. Operation Section 4-43...
Page 134 CROSS AND CUPS NEEDLE ROLLERS Load too high for joint. HAVE BRINELLED INTO CUP AND CROSS A84B 03/07 © 2007 Alamo Group Inc. OPERATION Replace Seal. Replace Oil Seal and Shaft. Replace Shaft or repair Race. Replace Seal. Replace Seal or use a sealant on O.D.
Page 135 DRIVELINE INTEGRAL Integral Shields deformed. SHIELDS RATTLING OR NOT TURNING FREELY Nylon Bearing worn. A84B 03/07 © 2007 Alamo Group Inc. OPERATION Replace part and then slow down or or raise Mower. Use protective device. Replace part. Replace part. Reduce speed and/or raise cutter.
Page 138: Lubrication
U-joints, gearbox, and/or driveshaft. Lubrication Fitting Location ITEM DESCRIPTION FREQUENCY U-Joints 8 hours Gearbox Check Daily Tailwheel Pivot 10 Hours Wheel Hubs Weekly Telescoping 8 hours A84B 03/07 © 2007 Alamo Group Inc. MAINTENANCE Maintenance Section 5-2...
Page 139: Gearbox
Tail Wheel Bearings are packed at the factory with heavy-duty bearing grease. Grease Fittings are provided in the Wheel Hub and Tail Wheel Beam. Grease after 10 hours of use. Figure Mnt-R-0107. A84B 03/07 Maintenance Section 5-3 © 2007 Alamo Group Inc.
Page 140: Driveline Lubrication
16 hours. FIGURE Mnt-0024. Make certain that the Driveline Integral Shields are free to telescope and rotate around the Driveline without binding. A84B 03/07 © 2007 Alamo Group Inc. MAINTENANCE FIGURE Mnt-0024. Do not force grease through the Needle Cup...
Page 141: Blade Servicing
Do not heat or weld on hard surface blades as this can alter material strength causing blades to fail in a hazardous manner that could cause injury. A84B 03/07 © 2007 Alamo Group Inc. MAINTENANCE (SGM-10) Maintenance Section 5-5...
Page 142: Blade Removal
IMPORTANT: Always recheck gearbox output shaft slotted blade carrier retaining nut torque after a few hours operation. Avoid personal injury. Do not work under cutter without support blocks to keep frame from falling. A84B 03/07 © 2007 Alamo Group Inc. MAINTENANCE Maintenance Section 5-6...
Page 143: Slip Clutch
Attach machine to tractor, set engine at approximately half throttle and quickly engage PTO. This procedure will break clutch facings loose and allow the proper torque to be maintained. Return nuts and bolts to original position. - See Mnt-R-0109. A84B 03/07 © 2007 Alamo Group Inc. MAINTENANCE Maintenance Section 5-7...
Page 144: Mower Storage
NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal engine oil. They do not apply if special graphited or molydisulphide greases or other extreme pressure lubricants are used. This applies to both UNF fine and UNC coarse threads. A84B 03/07 © 2007 Alamo Group Inc. MAINTENANCE Maintenance Section 5-8...
Page 146 LIMITED WARRANTIES 1.01. Alamo Industrial warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser 1.02. Manufacturer will replace for the Purchaser any part or parts found, upon examination at one of its factories, to be defective under normal use and service due to defects in material or workmanship.
Page 147 TO THE OWNER/OPERATOR/DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily find the information you need. The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety require- ments of tractor operators: REQUIRED OF THE OWNER:...
Page 148 A84B-SOM-03/07 P/N 00760989C Printed U.S.A...
