Fox 985-24-004 Manual

Eyelet end
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 985-24-004 and is the answer not in the manual?

Questions and answers

Related Manuals for Fox 985-24-004

Summary of Contents for Fox 985-24-004

  • Page 2 Chevrolet Toyota Dodge Universal Key Ford Universal Guides Reference Key Hummer Reference Guide Isuzu Mounting Hardware Jeep Service Land Rover Tools Mercedes-Benz Upgrades Nissan Notes Shox Need Love Too...
  • Page 3 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER CHEVROLET AVALANCHE 0-2" PERFORMANCE SERIES 2.0 COIL-OVER IFP SHOCK 985-02-018 $549.95 0-3" FACTORY RACE SERIES 2.5 COIL-OVER IFP SHOCK (PAIR) 883-02-028 $1,499.95 Requires Upper Control Arm FRONT 3" FACTORY RACE SERIES 2.5 COIL-OVER RESERVOIR SHOCK (PAIR) 880-02-525 $1,849.95 Requires Upper Control Arm...
  • Page 4 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER CHEVROLET SILVERADO 1500 HD (CONTINUED) 2001 - 2003 REAR 7-10" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 980-24-957 $309.95 Includes Billet Reservoir Clamp 2005 - 2006 CHEVROLET SILVERADO 1500 HD CLASSIC 0-1"...
  • Page 5 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER CHEVROLET SILVERADO 2500 HD (CONTINUED) Not For Use With Lift Kits That Change OE Mounts | Includes Billet 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 980-26-966 $429.95 Reservoir Clamp 7-9"...
  • Page 6 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER CHEVROLET SUBURBAN (CONTINUED) 0-2" FACTORY RACE SERIES 2.5 COIL-OVER RESERVOIR SHOCK (PAIR) - ADJUSTABLE 883-06-121 $2,199.95 0-3" FACTORY RACE SERIES 2.5 COIL-OVER IFP SHOCK (PAIR) 883-02-028 $1,499.95 Requires Upper Control Arm FRONT 3"...
  • Page 7 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER DODGE RAM 1500 (CONTINUED) 3.5-4.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-022 $309.95 Includes Billet Reservoir Clamp 3.5-4.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-022 $429.95 Includes Billet Reservoir Clamp 2002 - 2005 REAR...
  • Page 8 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER DODGE RAM 1500 STANDARD CAB PICKUP (CONTINUED) 5-6" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-024 $199.95 2006 - 2008 REAR 5-6" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-026 $309.95 Includes Billet Reservoir Clamp 5-6"...
  • Page 9 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD BRONCO 2-3" PERFORMANCE ELITE SERIES 2.5 COIL-OVER RESERVOIR SHOCK (PAIR) - ADJUSTABLE 883-06-195 $2,399.95 4 Door Only | With Sasquatch Package | Requires Upper Control Arm 2.5-3.5" PERFORMANCE ELITE SERIES 2.5 COIL-OVER RESERVOIR SHOCK (PAIR) - ADJUSTABLE 883-06-192 $2,399.95 2 Door Only | With Sasquatch Package | Requires Upper Control Arm 4 Door Only | Without Sasquatch Package | Requires Upper Control...
  • Page 10 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD F-150 HERITAGE (CONTINUED) REAR 0-2" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 980-24-651 $199.95 2004 FRONT 0-2" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-045 $199.95 REAR 0-2" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 980-24-678 $199.95 FORD F-250 SUPER DUTY...
  • Page 11 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD F-350 SUPER DUTY CAB & CHASSIS (CONTINUED) FRONT 5.5-7" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-164 $429.95 Includes Billet Reservoir Clamp 2017 - 2022 2.5-4" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-151 $199.95 REAR...
  • Page 12 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD F-350 SUPER DUTY CREW CAB PICKUP (CONTINUED) 4-5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-133 $399.95 Includes Universal Bracket 4-6" FACTORY RACE SERIES 2.5 RESERVOIR SHOCK (PAIR) 883-24-013 $1,149.95 4-6"...
  • Page 13 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD F-350 SUPER DUTY EXTENDED CAB PICKUP (CONTINUED) 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 980-24-647 $199.95 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-104 $309.95 Includes Billet Reservoir Clamp 0-1"...
  • Page 14 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD F-350 SUPER DUTY STANDARD CAB PICKUP (CONTINUED) 1.5-3" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-103 $309.95 Includes Billet Reservoir Clamp FRONT 1999 - 2004 1.5-3" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-103 $429.95 Includes Billet Reservoir Clamp...
  • Page 15 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD F-450 SUPER DUTY CAB & CHASSIS - CREW CAB (CONTINUED) 2-3.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-121 $309.95 Includes Universal Bracket 2-3.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-121 $429.95 Includes Universal Bracket...
  • Page 16 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD F-450 SUPER DUTY CREW CAB PICKUP 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-161 $309.95 Includes Universal Bracket 2017 - 2019 FRONT 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-161 $429.95 Includes Universal Bracket...
  • Page 17 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER FORD F-550 SUPER DUTY (CONTINUED) 4-5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-133 $309.95 Includes Universal Bracket 4-5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-133 $399.95 Includes Universal Bracket 4-6"...
  • Page 18 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER GMC SIERRA 1500 (CONTINUED) 2007 - 2018 REAR 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-194 $199.95 0-2" PERFORMANCE SERIES 2.0 COIL-OVER IFP SHOCK 985-02-018 $549.95 Does not fit magnetic suspension 2007 - 2013 FRONT 0-2"...
  • Page 19 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER GMC SIERRA 2500 (CONTINUED) 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 980-24-664 $199.95 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 980-24-955 $309.95 Includes Billet Reservoir Clamp 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 980-26-955 $429.95 Includes Billet Reservoir Clamp...
  • Page 20 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER GMC SIERRA 3500 HD 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-238 $199.95 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-242 $309.95 FRONT 1.5-2.5" PERFORMANCE ELITE SERIES 2.5 RESERVOIR SHOCK (PAIR) - ADJUSTABLE 883-26-084 $1,499.95 Requires Upper Control Arm...
  • Page 21 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER GMC YUKON XL 2500 (CONTINUED) 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 980-26-959 $429.95 Includes Billet Reservoir Clamp 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 980-24-658 $199.95 4-6"...
  • Page 22 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER JEEP CHEROKEE XJ 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-084 $199.95 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-107 $309.95 Includes Billet Reservoir Clamp 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-107 $429.95 Includes Billet Reservoir Clamp...
  • Page 23 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER JEEP GRAND CHEROKEE WJ (CONTINUED) 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-042 $199.95 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-109 $309.95 Includes Billet Reservoir Clamp 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-109 $429.95...
  • Page 24 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER JEEP WRANGLER JK (CONTINUED) 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-012 $309.95 Includes Billet Reservoir Clamp 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-012 $429.95 Includes Billet Reservoir Clamp 4.5-6"...
  • Page 25 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER LAND ROVER DISCOVERY (CONTINUED) 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-123 $309.95 Discovery 1, Includes Billet Reservoir Clamp 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK - ADJUSTABLE 985-26-123 $429.95 Discovery 1, Includes Billet Reservoir Clamp...
  • Page 26 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER NISSAN PATROL Y61 (CONTINUED) 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-227 $199.95 Does Not Fit Leaf Spring Models 0-2.5" FACTORY RACE SERIES 2.5 RESERVOIR SHOCK (PAIR) - ADJUSTABLE 883-26-070 $1,449.95 Includes Billet Reservoir Clamp | Does Not Fit Leaf Spring Models...
  • Page 27 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER RAM 2500 (CONTINUED) 2011 - 2022 STABILIZER PERFORMANCE SERIES 2.0 SMOOTH BODY IFP STABILIZER 985-24-170 $199.95 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 980-24-943 $199.95 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 980-24-945 $309.95 Includes Billet Reservoir Clamp...
  • Page 28 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER RAM 3500 CREW CAB PICKUP (CONTINUED) 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-259 $319.95 Fits Dually-Pickup Models Only REAR 4-6" PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK 985-24-264 $319.95 W/ Single Rear Wheels 2014 - 2016...
  • Page 29 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER TOYOTA FORTUNER (CONTINUED) REAR 0-1.5" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 985-24-124 $199.95 0-2" FACTORY RACE SERIES 2.5 COIL-OVER RESERVOIR SHOCK (PAIR) 883-02-092 $1,749.95 2005 - 2014 FRONT 0-2" FACTORY RACE SERIES 2.5 COIL-OVER RESERVOIR SHOCK (PAIR) - ADJUSTABLE 883-06-092 $2,199.95...
  • Page 30 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER TOYOTA TACOMA (CONTINUED) 0-1" FACTORY RACE SERIES 2.5 COIL-OVER IFP SHOCK (PAIR) 880-02-361 $1,499.95 Fits 6 lug version only 0-1" FACTORY RACE SERIES 2.5 COIL-OVER RESERVOIR SHOCK (PAIR) 880-02-376 $1,999.95 Fits 6 lug version only 0-1"...
  • Page 31 MAKE/ PART DRIVE POS. LIFT DESCRIPTION PRICE NOTE YEAR NUMBER TOYOTA TUNDRA (CONTINUED) 2000 - 2006 REAR 0-1" PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 980-24-674 $199.95...
  • Page 33 PART NUMBER PRICE PERFORMANCE SERIES 2.0 SMOOTH BODY IFP SHOCK 5.0" 16.32 11.30 985-24-002 $199.95 6.6" 20.02 13.40 985-24-003 $199.95 8.1" 22.72 14.60 985-24-004 $199.95 EYELET:EYELET 10.1" 26.91 16.80 985-24-005 $199.95 11.1" 29.02 17.90 985-24-068 $199.95 12.1" 31.82 19.70 985-24-006 $199.95...
  • Page 35 PART NUMBER EXT. LENGTH COL. LENGTH TRAVEL TOP MOUNT BOTTOM MOUNT RESERVOIR 880-02-361 22.59 18.04 4.55" Eyelet Internal Floating Piston (IFP) 880-02-376 21.46 16.91 4.55" Eyelet Remote 880-02-418 21.81 16.91 4.90" Eyelet Remote 880-02-525 19.40 14.10 5.30" Bar Pin Remote 880-02-634 22.27 16.90...
  • Page 36 PART NUMBER EXT. LENGTH COL. LENGTH TRAVEL TOP MOUNT BOTTOM MOUNT RESERVOIR 883-26-011 23.97 15.20 8.77" Remote 883-26-012 32.33 19.86 12.47" Piggyback 883-26-013 26.37 16.40 9.97" Remote 883-26-014 35.03 21.46 13.57" Piggyback 883-26-015 26.05 15.93 10.12" Remote 883-26-016 28.04 17.20 10.84"...
  • Page 37 PART NUMBER EXT. LENGTH COL. LENGTH TRAVEL TOP MOUNT BOTTOM MOUNT RESERVOIR 980-24-651 24.13 15.00 9.13" Internal Floating Piston (IFP) 980-24-652 27.32 16.69 10.63" Internal Floating Piston (IFP) 980-24-653 32.82 20.20 12.62" Internal Floating Piston (IFP) 980-24-654 22.72 14.60 8.12" Internal Floating Piston (IFP) 980-24-655 28.52...
  • Page 38 Eyelet Internal Floating Piston (IFP) 985-24-002 16.32 11.30 5.02" Internal Floating Piston (IFP) 985-24-003 20.02 13.40 6.62" Internal Floating Piston (IFP) 985-24-004 22.72 14.60 8.12" Internal Floating Piston (IFP) 985-24-005 26.91 16.80 10.11" Internal Floating Piston (IFP) 985-24-006 31.82 19.70 12.12"...
  • Page 39 PART NUMBER EXT. LENGTH COL. LENGTH TRAVEL TOP MOUNT BOTTOM MOUNT RESERVOIR 985-24-107 20.87 13.25 7.62" Remote 985-24-108 25.37 15.25 10.12" Remote 985-24-109 26.87 16.25 10.62" Remote 985-24-110 28.87 17.25 11.62" Remote 985-24-111 19.52 12.40 7.12" Remote 985-24-112 23.02 14.40 8.62"...
  • Page 40 PART NUMBER EXT. LENGTH COL. LENGTH TRAVEL TOP MOUNT BOTTOM MOUNT RESERVOIR 985-24-242 18.14 12.78 5.37" Clevis Remote 985-24-243 26.52 15.90 10.62" Remote 985-24-244 18.89 12.78 6.12" Clevis Remote 985-24-245 27.32 16.70 10.62" Remote 985-24-253 17.85 11.55 6.30" Stem Top Eyelet Internal Floating Piston (IFP) 985-24-257...
