DIRECT-REPLACEMENT
INSTALLATION GUIDE
FORD RANGER (19+)
985-02-133 - 19-ON Ford Ranger, Front Coil-over, PS, 2.0, IFP, 4.47", 0-3" Lift
883-06-156 – Kit: 19-ON Ford Ranger, Front, 2.5 Truck FRS, R/R, 4.05", 2-3" Lift, DSC
985-24-207 - 19-ON Ford Ranger, Rear, PS, 2.0, IFP, 9.7", 0-1.5" Lift
883-26-059 - 19-ON Ford Ranger, Rear, 2.5 Truck FRS, P/B, 9.55", 0-1.5" Lift, DSC
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fox 985-02-133
Summary of Contents for Fox 985-02-133
- Page 1 INSTALLATION GUIDE FORD RANGER (19+) 985-02-133 - 19-ON Ford Ranger, Front Coil-over, PS, 2.0, IFP, 4.47", 0-3" Lift 883-06-156 – Kit: 19-ON Ford Ranger, Front, 2.5 Truck FRS, R/R, 4.05", 2-3" Lift, DSC 985-24-207 - 19-ON Ford Ranger, Rear, PS, 2.0, IFP, 9.7", 0-1.5" Lift...
- Page 2 FORD RANGER (19+) 985-02-133 - 19-ON Ford Ranger, Thank you for choosing FOX direct- Front Coil-over, PS, 2.0, IFP, 4.47", 0-3" replacement shocks for your vehicle. Lift FOX products are designed, tested, and manufactured by the finest professionals 883-06-156 – Kit: 19-ON Ford Ranger, in the industry.
-
Page 3: Safety Instructions
Installation of vehicle roll bars or cage is the suspension clears the FOX shocks. highly recommended. • FOX direct-replacement shocks • FOX direct-replacement shocks are should always be installed as a pair for gas-charged and are highly pressurized. - Page 4 Once the spring is removed, you can adjust the preload ring. DO • DO NOT install any FOX product NOT Exceed more the 1/2" of additional without the necessary special tools, preload. If more than 1/2" of preload...
- Page 5 3. Remove front wheels from vehicle. 4. If equipped, remove the vehicle skid plate. 5. Disconnect the sway bar from the spindle on both sides of the vehicle. (Figure 1) Figure 3: Passenger side shown Figure 1: Passenger side shown 1.800.FOX.SHOX (369.7469) 619.768.1800 ORSERVICE@RIDEFOX.COM...
- Page 6 8. Disconnect the outer most ABS wire 10. Disconnect the outer tie rod end from clip from the upper control arm. the upright. (Figure 5) (Figure 4) Figure 4: Passenger side shown Figure 5: Passenger side shown 9. If equipped with 4x4, it is 11.
- Page 7 15. Once the stock coil-over is removed, you can now install your new FOX coil- over. With remote reservoir models, make sure that the hoses are facing outward and towards the front of the vehicle (Figure 7). Connect the coil- over top hat to the vehicle with the provided washers and nuts.
- Page 8 17. Reinstall upper control arm to upright and reattach any wires and brake lines previously removed from the upright and upper control arm. Torque to OEM specifications 18. If equipped with 4x4, reinstall outer axle into the hub and torque the nut to OEM specifications.
- Page 9 25. Installed coil-over will resemble Figure 12. 26. If equipped, reinstall skid plate, torque to OEM specifications. 27. Check that the suspension has proper clearance by steering completely in both directions. 28. Reinstall front wheels and torque to OEM specifications. 1.800.FOX.SHOX (369.7469) 619.768.1800 ORSERVICE@RIDEFOX.COM...
- Page 10 (Do not discard bolts and nuts, as Figure 13: Driver Side Shown, (Left: 2.5 Factory Race Series Shock, Right: 2.0 Performance Series IFP Shock) they will be used with your new FOX Shock.) 3. Install new FOX shock reusing OEM bolts and nuts.
- Page 11 FOX FACTORY SETTINGS DSC HIGH SPEED 12 CLICKS DSC LOW SPEED 10 CLICKS 1.800.FOX.SHOX (369.7469) 619.768.1800 ORSERVICE@RIDEFOX.COM...
- Page 12 (1) abnormal, excessive, or improper use. year from the date of the original FOX Should it be determined by FOX in its suspension product retail purchase sole and final discretion, that a FOX...
- Page 13 INCIDENTAL OR CONSEQUENTIAL THIS IS THE ONLY WARRANTY DAMAGES OR PUNATIVE DAMAGES. MADE BY FOX ON ITS SUSPENSION PRODUCTS AND COMPONENTS, AND This limited warranty does not apply to THERE ARE NO WARRANTIES WHICH normal wear and tear, malfunctions or...
- Page 14 RIDEFOX.COM 750 VERNON WAY SUITE 101. EL CAJON, CA 92020 USA...
- Page 15 1.800.FOX.SHOX (369.7469) 619.768.1800 ORSERVICE@RIDEFOX.COM...
- Page 16 RIDEFOX.COM 750 VERNON WAY SUITE 101. EL CAJON, CA 92020 USA 1.800.FOX.SHOX (369.7469) 619.768.1800 ORSERVICE@RIDEFOX.COM PN 605-01-258 REV A JUNE 2019...
