Fox PERFORMANCE ELITE 2.5 Installation Manual

Dual speed compression
Hide thumbs Also See for PERFORMANCE ELITE 2.5:
Table of Contents

Advertisement

Quick Links

DIRECT-REPLACEMENT
INSTALLATION GUIDE
TOYOTA TUNDRA (2022-ON)
PERFORMANCE ELITE 2.5
DUAL SPEED COMPRESSION
883-06-218 - Kit: 22-ON Toyota Tundra, Front Coilover, 2.5 Truck PES, R/R, DSC,
0-2.25" Lift
883-26-139 - Kit: 22-ON Toyota Tundra, Rear, 2.5 Truck PES, R/R, DSC, 0-1.5" Lift
883-26-141 - Kit: 22-ON Toyota Tundra, w/Ext Brake Lines, Rear, 2.5 Truck PES, R/R,
DSC, 1.5-3" Lift
605-01-367 REV A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PERFORMANCE ELITE 2.5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fox PERFORMANCE ELITE 2.5

Summary of Contents for Fox PERFORMANCE ELITE 2.5

  • Page 1 DIRECT-REPLACEMENT INSTALLATION GUIDE TOYOTA TUNDRA (2022-ON) PERFORMANCE ELITE 2.5 DUAL SPEED COMPRESSION 883-06-218 - Kit: 22-ON Toyota Tundra, Front Coilover, 2.5 Truck PES, R/R, DSC, 0-2.25” Lift 883-26-139 - Kit: 22-ON Toyota Tundra, Rear, 2.5 Truck PES, R/R, DSC, 0-1.5” Lift 883-26-141 - Kit: 22-ON Toyota Tundra, w/Ext Brake Lines, Rear, 2.5 Truck PES, R/R,...

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION SUPPLIED PART S SHOCK DIAGRAM SAFETY INSTRUCTIONS INSTALLATION GUIDELINES FRONT SHOCK INSTALLATION REAR SHOCK INSTALLATION FOX FACTORY DSC WARRANTY INFORMATION SHOCKS NEED LOVE TOO...

  • Page 3: Introduction

    FOX recommends that you become completely familiar with the handling characteristics of your modified vehicle before operating it under rigorous conditions, helping to avoid potential rollover situations and other loss of control events. FOX further recommends that you use appropriate protective equipment at all times when operating your vehicle.

  • Page 4: Supplied Part S

    FRONT SHOCK SUPPLIED PARTS FRONT SHOCK ASSEMBLY FOX PN DESCRIPTION NOTES 883-06-218-L/R LEFT/RIGHT SHOCK UCAs are required. FRONT RESERVOIR BRACKET ASSEMBLY FOX PN DESCRIPTION NOTES 026-01-095-1 LEFT RESERVOIR BRACKET Brackets mount the remote reservoirs 026-01-095-2 RIGHT RESERVOIR BRACKET to the vehicle.
  • Page 5 REAR SHOCK SUPPLIED PARTS REAR SHOCK ASSEMBLY FOX PN DESCRIPTION NOTES 883-26-139-L/R LEFT/RIGHT SHOCK 883-26-141-L/R LEFT/RIGHT SHOCK Extended brake lines are required. REAR RESERVOIR BRACKET ASSEMBLY FOX PN DESCRIPTION NOTES 026-01-279-1 RESERVOIR BRACKET Brackets mount the remote reservoirs 026-01-279-2 RESERVOIR BRACKET to the vehicle.

  • Page 6: Shock Diagram

    SHOCK DIAGRAM FRONT SHOCK REAR SHOCK PART NO. NAME PART NO. NAME Eyelet DSC adjuster Hose Reservoir Stem top Shock body Shaft Schrader valve Hose fitting Top hat Preload ring Shock Boot 605-01-367...

  • Page 7: Safety Instructions

    FOX direct-replacement shocks are gas-charged and are highly pressurized. Placing shocks in a vise or clamp, applying heat, or attempting to open or service the shock without the proper tools and training can result in SERIOUS INJURY or DEATH. Do not attempt to modify, puncture or incinerate a FOX direct-replacement shock absorber.

  • Page 8: Installation Guidelines

    • DO NOT install any FOX product without the necessary special tools, expertise and chassis lift or you will subject yourself to the risk of SERIOUS INJURY or DEATH. If you elect to not use a chassis lift...

  • Page 9: Front Shock Installation

    INSTALLATION GUIDELINES ON HOW TO PROPERLY ADJUST PRELOAD. NOTICE: The spring preload is set by FOX for a stock weight vehicle to last the life of the product. Any additional spring preload may negatively effect the life of the spring.
  • Page 10 RESERVOIR BRACKET INSTALL 7. Remove the four bolts that secure the sway bar to the vehicle’s frame. Move the sway bar forward to allow clearance for shock removal and installation (Fig.4). 8. Install the reservoir bracket and spacer blocks to the sway bar bracket’s mounting location with the Fig.
  • Page 11 NOTICE: Do not discard any OEM bolts, many are reused with the new FOX shock assembly. 12. If an aftermarket UCA is required with the FOX shock kit, install the UCA now. Follow the company’s required specifications. After installation, continue to step 16.
  • Page 12 NOTICE: Minor trimming of the fender liner or air dam may be required for reservoir fitment. 15. Attach the reservoir to the mounting bracket with the provided reservoir clamps and screws. (Fig. 11). Loosely pre-assemble the upper clamp assembly. Tighten the clamp to 50% when the reservoir is centered with proper hose positioning.
  • Page 13 17. Reinstall the tie rod end link (Fig. 14) and sway bar end link (Fig. 15). Torque all hardware to OEM specification. Secure the tie rod end link’s castle nut with a new cotter pin. Fig. 14: Tie rod end link. Fig.

  • Page 14: Rear Shock Installation

    REAR SHOCK INSTALLATION NOTICE: Medium-strength thread-lock is recommended on all bolts. 1. Please read the installation guidelines on page 5 for instructions on how to properly lift and secure the vehicle. STOCK SHOCK REMOVAL 2. Remove the rear wheels from the vehicle and support the rear axle. 3.
  • Page 15 (passenger side shown). FOX SHOCK INSTALL 7. Orient the FOX shock with the hose fitting pointed outward. Loosely install the stem top nut and lower shock mount bolt (Fig. 20). 8. Torque the lower bolt to OEM specification (Fig. 21). Tighten the stem top nut until there are 3-4 threads showing above the nut.

  • Page 16: Fox Factory Dsc

    FOX FACTORY DSC DUAL SPEED COMPRESSION (DSC) ADJUSTER SETTINGS DSC HIGH SPEED COMPRESSION 12 CLICKS CLOSED OPEN (FULL (FULL CLICKS CLOCKWISE) COUNTER CLOCKWISE) LEAST AMOUNT GREATEST AMOUNT OF COMPRESSION OF COMPRESSION DAMPING SOFTEST DAMPING FIRMEST DSC LOW SPEED COMPRESSION 10 CLICKS...

  • Page 17: Warranty Information

    Should it be determined by FOX in its sole and final discretion, that a FOX suspension product is covered by this warranty, it will be repaired or replaced, by a comparable model, at FOX’s sole option, which will be conclusive and binding. THIS IS THE EXCLUSIVE REMEDY UNDER THIS WARRANTY. ANY AND ALL OTHER REMEDIES AND DAMAGES THAT MAY OTHERWISE BE APPLICABLE ARE EXCLUDED, INCLUDING, BUT NOT LIMITED TO, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR PUNITIVE DAMAGES.

  • Page 18: Shocks Need Love Too

    NEED LOVE TOO FOX SERVICE AND UPGRADES HAVE YOUR FOX SHOCKS SERVICED BY FOX TECHNICIANS. CALL OUR OFF-ROAD AND TRUCK SERVICE CENTER AT 619.768.1800 TO GO OVER THE SERVICE AND UPGRADE OPTIONS AVAILABLE FOR YOUR PROD- UCT. ONCE YOU’VE SETUP YOUR SERVICE AND/OR UPGRADES YOU WILL RECEIVE A RETURN AUTHORIZATION NUMBER AND SHIPPING INSTRUCTIONS.
