Sea gull lighting Classico HC-224 Installation And Safety Instructions

INSTALLATION AND SAFETY INSTRUCTIONS
FOR YOUR SAFETY
WARNING: BE SURE THE ELECTRICITY TO THE WIRES YOU ARE
WORKING ON IS SHUT OFF. EITHER THE FUSE REMOVED OR
THE CIRCUIT BREAKER OFF .
GENERAL
You don't need special tools to install this fixture. Be sure to follow the
steps in the order given. Read instructions carefully. If you are unclear
as to how to proceed, consult a qualified electrician.
NOTE: Proper wiring is essential for the safe operation of this
fixture.
NOTE: This glass is handcrafted, the slight imperfections in the
glass add to the authenticity of the fixture.
TOP ASSEMBLY
SCREWS (Q)
CAGE SCREWS (S)
*OUTLET BOX
WITHOUT TAIL
ASSEMBLY (FIG. 3)
ROUND NUT (H)
PIPE (G)
FINIAL (F)
TOP ASSEMBLY (O)
TOP PLATE (R)
CAP NUTS (N)
ROUND NUT (H)
COUPLING (D)
BACKPLATE (M)
CENTER PIPE (C)
BREAK A
BREAK B
*NOT SUPPLIED
NOTE FOR FIXTURES THAT ARE SOLID BRASS:
Your handcrafted, solid brass lighting fixture has been coated
with a durable, baked on acrylic lacquer which gives maximum
protection against the weather. In time, however, the brightness
of the brass will tarnish giving way to an authentic old world
brass finish.
NOTE: To keep your solid polished brass fixture looking new for
years to come, regularly apply a good quality non-abrasive car
wax to all metal surfaces, giving the fixture an extra
protective coating.
GROUNDING & UNIVERSAL MOUNTING
GREEN
GROUNDING
SCREW (L)
(FIG. 1)
UNIVERSAL
MOUNTING
CAGE (P)
BAR (J)
Installation And
TAIL (E)
Safety Instruction
HC-224
Line art shown may not exactly match the fixture enclosed.
BREAK A
However, the installation instructions do apply to this fixture.
BREAK B
Fill In Item Number On Carton And
File This Sheet For Fixture Reference.
FINIAL (F)
BAR LOCK UP (FIG. 2)
*OUTLET BOX
*NOT SUPPLIED
ITEM#_______________
*OUTLET BOX
SCREWS (K)
MOUNTING
SCREWS (I)
*WIRE CONNECTOR
011005
