Step 1:
Before you start
assembly make
sure components
listed below are
in the package.
Step 2:
Insert plastic bush
(F) in tube (D).
D.
F.
Step 3:
I.
Using screw (A)
attach the tube
to the nut on
the back of the
frame with allen
key (I).
Step 4:
Place the cover
plate over the
wire cover tube
and position it
so that it fits
junction box.
I
N
S
T
A
L
L
A
T
I
O
N
I
N
S
T
R
U
C
T
I
O
N
S
Advertisement
Related Manuals for Amba RWH-SP
Summary of Contents for Amba RWH-SP
- Page 1 Step 1: Before you start assembly make sure components listed below are in the package. Step 2: Insert plastic bush (F) in tube (D). Step 3: Using screw (A) attach the tube to the nut on the back of the frame with allen key (I).
- Page 2 Step 7: Remove bushings (C) from tube and using the screws (B) fix the bushings to the wall. Make sure screws are secured in a header or a stud in the wall. * Models RWH-SP / RWH-SB Page 2...
- Page 3 Step 8: Mount the frame onto the bushings (C) that are fixed to the wall and make sure the tubes are flush against the bushing. Step 9: Tighten all the set screws (E) with the allen key (G). Do not over tighten. Make sure frame is firmly fixed to wall.
- Page 4 THIS INFORMATION APPLIES TO THE MODELS BELOW: FOR PLUG IN MODELS THE UNIT IS SUPPLIED RWH-SB WITH A cULus LISTED RWH-SP CORD WITH GROUNDED RWH-CB PLUG. RWH-CP RWP-SB INSTALLATION IS THE RWP-SP SAME AS THE HARD- RWP-CB WIRED MODEL, RWP-CP EXCLUDING: RWH - Wall mounted &...
