Delancey
®
Single Control Lavatory Faucet
Thank you for selecting American Standard...
the benchmark of fine quality for over 140 years.
To ensure that your installation proceeds smoothly-please read
these instructions carefully before you begin.
RECOMMENDED TOOLS
Adjustable Wrench
1
INSTALL LAVATORY FAUCET
• Seat SEAL (1) into groove in under side of ESCUTCHEON BASE (2).
• Seat ESCUTCHEON BASE (2) with collar facing up into groove
in faucet base.
• Feed FAUCET SUPPLIES (3) and MOUNTING SHANK (4) through
hole in mounting surface.
• From below, install GASKET (5) and MOUNTING NUT (6) onto
SHANK (4). Secure Faucet with MOUNTING NUT (6). Before final
tightening, adjust Faucet so that it is centered. Tighten MOUNTING
NUT (6) to complete faucet mounting.
HOT LINE FOR HELP
For toll-free information and answers to your questions, call:
1 (800) 442-1902
Mon. - Fri. 8:00 a.m. to 8:00 p.m. EST
Saturday 10:00 a.m. to 4:00 p.m. EST
IN CANADA 1-800-387-0369
(TORONTO 1-905-306-1093)
Weekdays 8:00 a.m. to 7:00 p.m. EST
IN MEXICO 01-800-839-1200
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2018
INSTALLATION
INSTRUCTIONS
Plumbers' Putty or Caulking
Turn off hot and cold water
CAUTION
supplies before begining.
- 1 -
7052121
7052124
Regular Screwdriver
Phillips Screwdriver
1
4
5
6
3
Certified to comply with ANSI A112.18.1M
Channel Locks
2
GROOVE IN
(FAUCET BASE)
MOUNTING
SURFACE
M965991 (10/18)
Advertisement
Related Manuals for American Standard Delancey 7052121
Summary of Contents for American Standard Delancey 7052121
- Page 1 Delancey ® 7052124 Single Control Lavatory Faucet Thank you for selecting American Standard... the benchmark of fine quality for over 140 years. To ensure that your installation proceeds smoothly-please read these instructions carefully before you begin. Certified to comply with ANSI A112.18.1M...
- Page 2 MAKE WATER SUPPLY CONNECTIONS • Turn off hot and cold water supplies before beginning. • Connect FLEXIBLE SUPPLIES (1, 2) directly to wall supplies. Connection on fitting supplies are 3/8" compression. Connect left supply to Hot and right supply to the Cold wall supply.
- Page 3 TEST INSTALLED FAUCET AND CHECK FOR LEAKS • With HANDLE (1) in OFF position, turn on WATER SUPPLIES (2) and check all connections for leaks. COLD • Remove AERATOR (3). • Operate HANDLE (1) to flush water lines thoroughly. • Replace AERATOR (3). COLD SERVICE Turn off hot and cold water...
