Delancey
®
Centerset Lavatory Faucet
Thank you for selecting American Standard...
the benchmark of fine quality for over 140 years.
To ensure that your installation proceeds smoothly-please read
these instructions carefully before you begin.
RECOMMENDED TOOLS
Screwdriver
1
INSTALL FAUCET
• Apply a bead of PUTTY along the edge of the
underside of the BODY. Insert FAUCET (1)
through mounting holes of Sink or mounting
surface. Fig. A.
• Assemble LOCKNUTS (2) onto SHANKS (3) from
under side of Sink. Hand tighten firmly. Fig. B.
(HAND TIGHTEN)
Fig. B.
HOT LINE FOR HELP
For toll-free information and answers to your questions, call:
1 (800) 442-1902
Mon. - Fri. 8:00 a.m. to 8:00 p.m. EST
Saturday 10:00 a.m. to 4:00 p.m. EST
IN CANADA 1-800-387-0369
(TORONTO 1-905-306-1093)
Weekdays 8:00 a.m. to 7:00 p.m. EST
IN MEXICO 01-800-839-1200
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2018
INSTALLATION
INSTRUCTIONS
Channel Locks
Turn off hot and cold water
CAUTION
supplies before begining.
2
3
7052207
Adjustable Wrench
Fig. A.
1
PUTTY
3
SINK OR
MOUNTING
SURFACE
- 1 -
Certified to comply with ANSI A112.18.1M
Tubing Cutter
2
M965986 (10/18)
Advertisement
Related Manuals for American Standard Delancey 7052207
Summary of Contents for American Standard Delancey 7052207
- Page 1 7052207 Delancey ® Centerset Lavatory Faucet Thank you for selecting American Standard... the benchmark of fine quality for over 140 years. To ensure that your installation proceeds smoothly-please read these instructions carefully before you begin. Certified to comply with ANSI A112.18.1M...
- Page 2 INSTALL DRAIN FROM BELOW FIXTURE REAR OF SINK DRAIN OUTLET • Install DRAIN (1) by dropping it from the top of the sink. • Thread TAIL PIECE NUT (1) clockwise onto DRAIN BODY (2). • From under side of SINK install GASKET (2) and MOUNTING NUT (3).
- Page 3 TEST INSTALLED FITTING • With HANDLES (1) in OFF position, turn on WATER SUPPLIES (2) and check all connections for leaks. • Remove AERATOR (3). • Operate both HANDLES (1) to flush water lines thoroughly. • Replace AERATOR (3). CHECK DRAIN CONNECTIONS •...
