American Standard is devoted to making life,
in the heart of your home, better every day...
...so, thank you for inviting us in! With the very best in kitchen
and bathroom products, we are here to help make your life
happier, healthier and simpler. Our commitment to quality,
innovation and performance has made us part of your everyday
routine for nearly 150 years, and we look forward to being a
part of your life for many years to come.
Learn more at www.AmericanStandard.com
REGISTER YOUR WARRANTY
Try the easy-scan QR code to quickly enter
your information or find your product's
detailed warranty here:
www.AmericanStandard.com/warranty
Registering allows you to keep your product information
safe, and us the ability to contact you in the event of a
product recall or any news about your purchase.
And if ever you have a question or need help...?
Call us at 1-855-815-0004
M985164 EN (7/23)
702B405/702B505/702B605
Advertisement
Related Manuals for American Standard loT Detectlnk Paradigm 702B405
Summary of Contents for American Standard loT Detectlnk Paradigm 702B405
- Page 1 American Standard is devoted to making life, in the heart of your home, better every day… …so, thank you for inviting us in! With the very best in kitchen and bathroom products, we are here to help make your life happier, healthier and simpler.
-
Page 2: Inside The Box
Drill Screwdriver Wrench NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Selectronic Products visit our website at: ® www.americanstandard-us.com or e-mail us at: ASdetectlnk@lixil.com For Parts, Service, Warranty or other Assistance,... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS SPOUT ASSEMBLY INSTALLATION Turn off hot and cold water supplies before beginning. MPORTANT: Do not use putty when installing faucet without escutcheon. 1. Make sure O-RING (1) is installed in spout base. IMPORTANT: Do not use putty when installing faucet without escutcheon. - Page 4 CONTROL BOX INSTALLATION VERTICAL 1. Remove the SCREW (4) from the bottom of the control box and lift the cover off. 2. Determine the mounting location of the control box by checking HORIZONTAL the wire length of the faucet and flow sensor when connected to the control box.
- Page 5 #4SD1 OR EQUAL (BY OTHERS). to HARD-WIRED AC TRANSFORMER (3) and mount on ELECTRICAL BOX (5). CAUTION: Use only American Standard supplied transformers and cable sets. Using non-AS supplied cables, or cutting, splicing or modifying any components will void the warranty.
- Page 6 MULTI-AC VERSION (DAISY CHAIN) Unit #1 Unit #2 Unit #3 Unit #4 (Already Installed) BLACK & WHITE POWER CONNECTIONS MAXIMUM OF 8 UNITS PER TRANSFORMER. 10' MAXIMUM CABLE LENGTH BETWEEN UNITS. Important: Disconnect the first unit’s Multi-AC Adapter from power supply before making daisy-chain connections.
- Page 7 REMOVE MIXING HANDLE Adjust hot limit safety To reduce the amount of hot water that can mix with cold, the installer can adjust hot limit stop (Four different settings). 1. Rotate Lever Handle (5) counter-clockwise to its stop position (100% cold). 2.
- Page 8 HAND WASH SENSOR OPERATION REMOVE PROTECTIVE FILM FROM SENSOR EYE WHEN INSTALLATION IS COMPLETE. When the Sensor detects a user, the water immediately starts to flow. Water flow will stop 1.5 seconds after user is out of sensor range. This Comfort delay allows the user to comfortably move their hands without the water turning off.
-
Page 9: Maintenance
MAINTENANCE REPLACE BATTERY 1. Remove control box cover by unthreading SCREW (3). 2. Disconnect Battery (1) from WIRE (2). 3. Connect the new battery to WIRE (2). 4. Check that the new battery is successfully activating the faucet. 5. Cover control box with the cover and SCREW (3). REPLACE BACK-UP BATTERY KIT FOR AC VERSION Remove old back-up battery by disconnecting the two wires. - Page 10 GENERAL CLEANING 1. Only use a damp, soft cloth to clean the spout and the sensor. 2. For tougher dirt, use a soft cloth with diluted dish washing detergent. Wipe the area using a wet cloth and dry using a soft cloth. CAUTION Do not scratch the sensor when cleaning.
- Page 11 Fully open external supply stops by turning partially closed. counter clockwise. Inspect flow sensor assembly, aerator and Running low flow issues. solenoid valve. Remove, clean and insert back Check for blockage. to original position. NOTE: Aerator must only be serviced with appropriate American Standard repair parts.
- Page 12 TROUBLE SHOOTING GUIDE FOR FAUCET CONT’D PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Double check power connections and supply. Device lost power. If using AC version, check backup battery & replace. Device is not communicating. Multi AC power cable was not Ensure that cable is securely connected. connected.
- Page 13 APPENDIX A Supplier’s Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier: IoT Detectlnk Paradigm and 702B405 / 702B505 / 702B605 Responsible Party : AS America, Inc. d/b/a LIXIL Americas Address : AS America, Inc. d/b/a LIXIL Americas 865 Centennial Ave.
-
Page 14: Tell Us What You Think
Register your sink at www.americanstandard.com. Please save your proof of purchase (sale receipt). If you need assistance or do not have access to our website, please contact American Standard Customer Care at: (800) 442-1902. An American Standard representative will assist in completing the warranty registration.
