Ram Mounts Tough-Strap RAP-460-UN10U Manual

Part Index
*not to scale
A B
x1 x1
Select proper strap (B or C) and rubber strip (D or E) to fit the following rail diameters:
Diameter
0.875" - 1"
1" - 1.125"
1.125" - 1.25"
1.25" - 1.38"
Adhere (D or E) Rubber Strip to (B or C) Strap. See the chart above to
1
determine the correct sizes for your handlebar.
Safety Precaution
Do not install this product near or over an airbag deployment area or in a location that obstructs the driver's vision or interferes with vehicle
operation. National Products, Inc does not assume responsibility or liability for any such personal injury, death or property damage.
To see more mounting options, visit RamMount.com
rammount.com
1.800.497.7479
support@rammount.com
C
x1
This document, including images, may not be reproduced partly or fully without the expressed written consent of National Products, Inc.
D E
x1 x1
Strap
Short (B)
Short (B)
Long (C)
Long (C)
Connect remaining parts as outlined in the diagram below.
2
B or C
G
RAM Tough-Strap
®
Handlebar Ball Base
F G
x1 x1
Rubber Strip
Short (D)
Long (E) - Cut to Fit
Short D)
Long (E)
A
F
RPR-INS-B-460
™
