Ram Mounts GDS RPR-INS-GDS-DOCKL-V2 Quick Manual

Note: Top cup may vary
Parts
index
Adhere foam pads to the inside
1
of top cup. Position evenly on top
cup, and cutting around any open
holes as needed.
Using (K) screws, attach bottom docking cup to vehicle
4
dock assembly.
7
Insert top slide over internal vehicle dock.
For questions regarding the assembly of this holder, contact us at:
Phone: 1-800-497-7479 Email: support@rammount.com
To see more mounting options, visit rammount.com To see more mounting options, visit rammount.com
Phone: 1.800.497.7479
w w w. r a m m o u n t . c o m
support@rammount.com
Position (H) nuts in nut pockets,
2
guiding them in place with a pen.
This document, including images, may not be reproduced partly or fully without the expressed written consent of National Products, Inc. This document, including images, may not be reproduced partly or fully without the expressed written consent of National Products, Inc.
GDS
TAB-LOCK™
While holding (H) nuts in place, attach ball adapter to back
3
of holder using (G) screws. RAM
shown direction. Attach additional (L) screws.
Using (K) screws, attach top
5
docking cup to top slide with
numbers facing down.
Place (N) nuts into top slide,
8
aligning with holes in internal slide.
Locking Vehicle Dock
®
2x
J K L G
M
10x
4x 2x 2x 2x
logo must be facing in the
®
Note: Ball adapter not included
6
Twist key lock to release
internal slide.
Attach (M) screws from behind the
9
internal slide. Do not fully tighten
(slides must remain loose).
RPR-INS-GDS-DOCKL-V2
2x
H
N
2x
2x
