- Page 5 Insert wooden dowel (A) into parts (6,7), secure cam bolt (C) into parts (4,5) as per diagram.
- Page 6 Secure cam bolt (C) into parts (1,2) with Philips head screwdriver as per diagram.
- Page 7 Using cam lock(B) secure parts (6,7) to part (2) with Philips head screwdriver as per diagram.
- Page 8 Using screw (D) attach part (8) into parts (6,7) with hex key (E) as per diagram.
- Page 9 Using cam lock(B) secure parts (4,5) to part (3) with Philips head screwdriver as per diagram.
- Page 10 Using cam lock(B) secure parts (4,5) to part (2) with Philips head screwdriver,then using bolt (F) attach connecting iron sheet (H) with Hex key (E) as per diagram.
- Page 11 Repeat last step as per diagram.
- Page 12 Insert wooden dowel (A) as per diagram.
- Page 13 Using cam lock (B) secure part (1) into parts (2,3) with Philips head screwdriver as per diagram.
- Page 14 Place sticker (G) cover the holes as per diagram .
