- Page 1 USER MANUAL MODEL NUMBER: FI-30N-SM FI-30NK-SM FI-30NV-SM AND RELATED UNITS 30 Gallon Smart Foam Unit English (Original Instructions)
-
Page 2: Protect The Environment
• Always rinse and drain unit after use (as described in the After Use Instructions). Always store unit disconnected from the compressed air source. • Do not exceed an incoming air pressure of 100 psi (7 bar). • Do not exceed a fluid temperature of 100˚F (37˚C). • Always flush the unit with fresh water for 5 minutes when switching from an alkaline to an acid or an acid to an alkaline. • Only use clean and dry air. Air must be filtered and free of moisture or pump life will be diminished. If needed, install a water separator (WS-20CFM) before the unit. • Do not use an air lubricator before the unit. PROTECT THE ENVIRONMENT Please dispose of packaging materials, old machine components, and hazardous fluids in an environmentally safe way according to local waste disposal regulations. Always remember to recycle. *Specifications and parts are subject to change without notice. Model No.: FI-30N-SM, FI-30NK-SM, FI-30NV-SM AND RELATED UNITS Page 2 of 9 | 03302015... - Page 3 Compressed air Chemical pickup type Draws from pre-mixed solution Number of products unit can draw from One product Capacity 30 gallons (132.15 liters) Discharge hose diameter/length 30 ft. (9.1 m) bonded hose, with 5/8 in. (15.9 mm) and 1/4 in. (6.4 mm) inside diameter Discharge wand/tip type Ultra high molecular weight (UHMW) polyethylene handle and wand extension, with 65 fan tip and built-in zero tip Output distance With zero tip: 17-21 ft. (5.2 m – 6.4 m) With fan tip (ST65150): 16-20 ft. (4.9 m – 6.1 m) Output volume With zero tip: 20-32 gal/min (75-121 l/min) of foam With fan tip (ST65150): 20-32 gal/min (75-121 l/min) of foam Flow rate* 2 gal/min (7.6 l/min) Pump seals Santoprene, Viton, or Kalrez Wheel type Two 10 inch non-marking wheels, two 5 inch casters with lock *Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings. Model No.: FI-30N-SM, FI-30NK-SM, FI-30NV-SM AND RELATED UNITS Page 3 of 9 | 03302015...
-
Page 4: After Use Instructions
8. Release the air trigger to stop foaming. Note: When you release the air trigger, the unit will shut off and depressurize. Foam that is already in the discharge hose may seep out, but no more foam will be created until you cover the air trigger again. After Use Instructions: 1. Open the drain plug (DP-A) and drain the unit tank. 2. Rinse the unit tank thoroughly with fresh water. Then replace the drain plug and fill the tank with fresh water. 3. Activate the unit and allow it to run for 2-4 minutes, or until all chemical has been flushed from the system. 4. Open the drain plug (DP-A) and drain any water remaining in the unit tank. Then replace and secure the drain plug. 5. Disconnect the air line from the air fitting (AP25). 6. Allow any liquid remaining in the discharge hose to drain out through the discharge wand before storing the unit. Model No.: FI-30N-SM, FI-30NK-SM, FI-30NV-SM AND RELATED UNITS Page 4 of 9 | 03302015... -
Page 5: Troubleshooting Instructions
(3.4 bar) on the air guage (AG100). 2. If the air supply is 50 psi (3.4 bar) or above, check 2. If the problem persists, the valve block (SM-PV) may the air gauge (AG100), which should read near 50 psi need to be replaced. (3.4 bar). If the air gauge reads more or less than 50 psi (3.4 bar), adjust the pressure by turning the knob on the top of the air regulator (R25). 3. If the problem persists, the stainless steel mixing mesh (SS-MESH) inside the tee fitting (SST12HB38) could be plugged. Remove and clean the mesh following the instructions below: a. Ensure that the unit has been flushed and disconnected from the air supply according to the “After Use Instructions.” Also ensure that the unit tank is empty, and/or that the valve (PVCV34FM) at the base of the suction line is closed. b. Remove the stainless hose barb (HBSS1258) from the tee fitting (SST12HB38). Model No.: FI-30N-SM, FI-30NK-SM, FI-30NV-SM AND RELATED UNITS Page 5 of 9 | 03302015... - Page 6 AHB-3816 TANK-30N FWAX15 FWAX15 SSAXEL20.5 AS1-VS SSP12 DP-A PVCV34FM CST5SS-L CST5SS WAND ASSEMBLY DISCHARGE HOSE ASSEMBLY ITEM NUMBER: SMWA ITEM NUMBER: H5814-30 ST65150 PW1238 Air Trigger Port SSC14 SSC58 HBSS1814 HBSS1258 Model No.: FI-30N-SM, FI-30NK-SM, FI-30NV-SM AND RELATED UNITS Page 6 of 9 | 03302015...
- Page 7 ITEM NUMBER: PA-PF-SM HBSSEL1438 NV14Y HBSS1438 P56-BRKT-SCREW SN1414 AG100 P56, P56K, or P56V BPS-58SO P56-BRKT BPS-SSR SM-PV HBBEL1414 EC14-2 HBSSEL1438 HBSSEL1438 H14B-H (Available per .) CV38 H38B-H SST12HB38 (Available per .) SSC38 Model No.: FI-30N-SM, FI-30NK-SM, FI-30NV-SM AND RELATED UNITS Page 7 of 9 | 03302015...
-
Page 8: Back Plate
User Manual: 30 Gallon Smart Foam Unit | English READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT BACK PLATE Outside View BPS-58S0 TW916 NV14Y SSA14 AP25 FWLG14 HBSS1414 HBSS1258 FWP12 SUCTION LINE BPS-58SO BPS-58SO STR38-IL HHPB3414 SSC38 HBSSEL1438 PVCV34FM Model No.: FI-30N-SM, FI-30NK-SM, FI-30NV-SM AND RELATED UNITS Page 8 of 9 | 03302015... - Page 9 ST65150 VEEJET NOZZLE 65150 - 3/8 MPT HBSS1438 STAINLESS HOSE BARB 1/4 MPT X 3/8 BARB STR38-IL IN LINE STRAINER 3/8 BARB 20 MESH 304 STAINLESS EDPM GSKT HBSS1814 1/8 MPT X 1/4 STAINLESS HOSE BARB TANK-30N ROTO MOLDED 30 GALLON UNIT W/ HANDLE HBSSEL1438 STAINLESS HOSE BARB ELBOW 1/4 INCH NPT X 3/8 HOSE BARB FI-30N-HNDL 30 GAL PORTABLE UNIT-NATURAL-HANDLE ONLY- INCLUDES BOLTS AND WASHERS HHPB3414 HEX HEAD POLY REDUCER BUSHING 3/4 X 1/4 TW916 1/2 INT TOOTH L/W 410SS NV14Y FLOW CONTROL VALVE - INCLUDES BLACK KNOB NONMARKING WHEEL FOR PORTABLE UNITS NV14Y-HNDL BLACK KNOB FOR NEEDLE VALVE - 2839-1/4 Model No.: FI-30N-SM, FI-30NK-SM, FI-30NV-SM AND RELATED UNITS Page 9 of 9 | 03302015...
