- Page 1 YAUFEY Home Dehumidifier Please read this manual carefully before using the product JD026R-150 USER MANUAL www.yaufey.com...
-
Page 2: For Customers
REQUESTING CUSTOMER SERVICE If there are any problems of the product,please contact Yaufey Customer Service support@yaufey.com with your Purchase Order ID.We'll help you solve the... -
Page 3: Before First Use
BEFORE FIRST USE: To protect the product from any internal damages,please keep the product in the upright position throughout its journey. Please take out the product and leave it standing in the upright position for 24 HOURS before plugging it in. -
Page 4: Table Of Contents
YAUFEY TABLE OF CONTENTS FEATURES................01 SAFETY PRECAUTIONS ..........02 IMPORTANT SAFETY INSTRUCTIONS...... 04 SPECIFICATIONS ............17 PRODUCT DIAGRAM............18 OPERATION INSTRUCTIONS........19 DRAINAGE ............... 21 MAINTENANCE& CLEANING........24 TROUBLESHOOTING............ 25 SPECIALNOTES............26 WARRANTY& CONTACT US......... 27... -
Page 5: Features
FEATURES FEATURES Powerful Moisture Removal With the cutting-edge technology,the dehumidifier powerfully removes moisture from the air to reduce the room humidity level and keep the indoor air dry and comfortable. Lightweight Portable Design The dehumidifier is built to be compact and lightweight.The casters on the bottom of the unit make it easy to move from room to room. -
Page 6: Safety Precautions
SAFETY PRECAUTIONS IMPORTANT NOTICE FOR FIRST USE: For your safety,please read the manual carefully and keep it for future reference. Please install and use this product according to the instructions in the manual. ·Please unplug the power cord before cleaning or storing the machine ●The machine can be used indoor except for laundry rooms. -
Page 7: Storing The Dehumidifier
SAFETY PRECAUTIONS WARNINGS ● Do not accelerate the defrosting process or clean the ice by yourself,other than those recommended by the manufacturer. ● Do not pierce or burn the machine. ● Be aware that refrigerants may not have an odour. ●... -
Page 8: Important Safety Instructions
Important Safety Instructions General Safety Instructions ●The dehumidifier is only suitable for indoor use,and is not suitable for other applications. ● Place the machine in a flat and dry place and keep a distance of above 18in between the machine and the surrounding objects or walls. ●Please ensure that the power plug is intact and firmly plugged into the power outlet,and place the power cord orderly to prevent someone from being tripped or pulling out the plug. - Page 9 Important Safety Instructions ·Ifthe supply cord is damaged,it must be replaced by the manufacturer,its service agent or similarly qualified persons in order to avoid a hazard. ·The appliance shall be stored so as to prevent mechanical damage from occurring. ·The appliance shall be installed in accordance with national wiring regulations. Special Safety Instructions for using flammable refrigerant 1.Transport of equipment containing flammable refrigerants...
- Page 10 Important Safety Instructions 6-1 Checks to the area ● Prior to beginning work on systems containing flammable refrigerants,safety checks are necessary to ensure that the risk of ignition is minimised. ● For repair to the refrigerating system,the following precautions shall be complied with prior to conducting work on the system.
- Page 11 Important Safety Instructions sufficiently far away from the site of installation,repairing,removing and disposal,during which flammable refrigerant can possibly be released to the surrounding space. ●Prior to work taking place,the area around the equipment is to be surveyed to make sure that there are no flammable hazards or ignition risks."No Smoking" signs shall be displayed.
- Page 12 Important Safety Instructions 6-9 Checks to electrical devices safety ● Repair and maintenance to electrical components shall include initial checks and component inspection procedures. ·Ifa fault exists that could compromise safety,then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with. ·If the fault cannot be corrected immediately but it is necessary to continue operation,an adequate temporary solution shall be used.
- Page 13 Important Safety Instructions 8.Repair to intrinsically safe components ● Do not a manent inductiv or capac tance ircu with at hn iy s eirl ensuring l not exceed the ermissib e volt nt p mitt for the equipment in use. ●Intrinsically safe components are the only types that can be worked on while live in the presence of a flammable atmosphere.The test apparatus shall be at the correct rating.
- Page 14 Important Safety Instructions -Leak detection fluids are suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work. -If a leak is suspected,all naked flames shall be removed/extinguished. -Ifa leakage of refrigerant is found which requires brazing,all of the refrigerant shall be recovered from the system,or isolated (by means of shut off valves)in a part of the system remote from the leak.
- Page 15 Important Safety Instructions ·This operation is absolutely vital ifbrazing operations on the pipe-work are to take place. ● Ensure that the outlet for the vacuum pump is not close to any ignition sources and there is ventilation available. 13.Charging procedures ·In addition to conventional charging procedures,the following requirements shall be followed: -Ensure that contamination of different refrigerants does not occur when using...
- Page 16 Important Safety Instructions b)Isolate system electrically. c)Before attempting the procedure ensure that: -Mechanical handling equipment is available,if required,for handling refrigerant cylinders; -All personal protective equipment is available and being used correctly; -The recovery process is supervised at all times by a competent person; -Recovery equipment and cylinders conform to the appropriate standards.
- Page 17 Important Safety Instructions ● When transferring refrigerant into cylinders,ensure that only appropriate refrigerant recovery cylinders are employed. ● Ensure that the correct number of cylinders for holding the total system charge is available ·All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant (i.e.special cylinders for the recovery of refrigerant).
- Page 18 Important Safety Instructions ·If compressors or compressor oils are to be removed,ensure that they have been evacuated to an acceptable level to make certain that flammable refrigerant does not remain within the lubricant. ·The evacuation process shall be carried out prior to returning the compressor to the suppliers.
- Page 19 Important Safety Instructions ·If the refrigerant is flammable the dehumidifier equipment shall have red,Pantone@ Matching System(PMS)#185 marked service ports,pipes,hoses,and other devices through which the refrigerant is serviced.This colour shall be present at all service ports and where service puncturing or otherwise creating an opening from the refrigerant circuit to the atmosphere might be expected (e.g.,process tubes).The colour mark shall extend at least 25 mm(1 inch)from the refrigerant servicing point and shall be replaced if removed...
- Page 20 Important Safety Instructions 1.3 Explanation of symbol displayed on the unit. ● This symbol shows that this appliance uses a flammable refrigerant ●If the flammable refrigerant WARNING is leaked and exposed to an external ignition source,there Caution,risk of fire is a risk of fire Avertissement:risque d'incendie/matériaux nflammables...
-
Page 21: Specifications
SPECIFICATIONS JD026R-150 MODEL 115V~60Hz POWER SOURCE TOTAL INPUT CURRENT 7.5A MOISTURE REMOVAL(65F,60%RH 49.72 PINTS (23.51 L/DAY) MOISTURE REMOVAL(80F,60%RH) 70 PINTS (33.11 L/DAY) MOISTURE REMOVAL(86F,80%RH) 120 PINTS (56.76 L/DAY) MOISTURE REMOVAL(95°F,90%RH) 150 PINTS (70.95 L/DAY) INPUT POWER(65°F,60%RH) 500W INPUT CURRENT(65°F,60%RH 4.4A IEF(65°F,60%RH) -
Page 22: Product Diagram
PRODUCT DIAGRAM Parts Continuous drainage hose 1.Control panel 2.Handle 3.Water bucket 6.Drain hose outlet 4.Air intake 5.Air outlet 8.Power cord buckle 7.Power cord 9.Caster —18—... - Page 23 OPERATING INSTRUCTIONS HIEH DEFROS CoNT INICUS POWER SWING TI M ER LOCK FANSPEED MODE Humidity Level&Timer Display 1.When the machine is powered on,it will indicate the current room humidity. 2.When you set the humidity,it will indicate the humidity that you have set. 3.When you program the timer,it will show the timing duration.
-
Page 24: Operation Instructions
OPERATING INSTRUCTIONS ”FAN SPEED: FAN SPEED Press“ ”button as follows:You can press this buton to adjusthe fan speed between low and high level.The corresponding indicator light will turn on when the fan speed is set. ”Humidity Setting “ ”“ Humidity Setting:Press“②”or“⑦”totpreset your desired humidity level. The humidity is adjustable between 30%RH to 80%RH in 5%H increment.The default humidity is 40%RH.When the humidity reaches the setting,the compressor stops and the "ECO"LED lights up. -
Page 25: Drainage
DRAINAGE ② , SWING Setting: SWI NG button and the swing light will turn on.The fan blades will Press the move up and down 40~80 degrees.Press the button again to stop the blades immediately ⑥ ”LOCK Setting After long pressing the timing button for 3 seconds,the lock key function is turned on,the lock light is on and the other keys are invalid after the lock key.Only after pressing the timing button again for 3 seconds to cancel the lock button function, will the other keys will be effective after the lock lamp is off. -
Page 26: Continuous Drainage
DRAINAGE NOTE 1.Do not remove the float from the water tank.The full tank sensor will no longer be able to detect the water level correctly without the float and water may leak from the tank. 2.If the tank is dirty,please wash it with cold or lukewarm water.Do not use detergent,scouring pads,chemically treated dust cloths,gasoline,benzene, thinner,or other solvents,as these may scratch and damage the tank and cause water leakage. - Page 27 DRAINAGE CONTINUOUS DRAINAGE (WITH NORMALDRAINAGE HOSE) The drainage hose has to be assembled smoothly like Fig.1. The hose cannot be distorted or has substantial turning.The hose cannot be higher than the water outlet.Keep the hose not blocked.Do not use extension tubes or replace it with other different hoses.
-
Page 28: Maintenance&Cleaning
MAINTENANCE&CLEANING Cleaning the Dehumidifier To Clean the Machine Wipe it with a soft damp cloth. Cleaning the Air Filter 1.Open the inlet grill firstly and wash with water 2.Clean the air filter Run a vacuum cleaner lightly over the surface of the air filter to remove dirt.If the air filter is exceptionally dirty,wash it with warm water and a mild cleanser and dry thoroughly. -
Page 29: Troubleshooting
TROUBLESHOOTING If a condition listed below occurs,please check the following items before calling customer service. Problems Possible Causes Solutions Plug the power cord into Has the power cord been disconnected? the outlet Empty the water in the drainage Is the tank full indicator The unit doesn't Hlashing?(The tank is tank and then reposition... -
Page 30: Specialnotes
SPECIALNOTES When using the machine,please Do not insert any thin rods or When using the machine, keep it away from any heating hard items into the machine to please do not put it on a soft furnaces,electric kettles and prevent malfunctions and or uneven ground to prevent other heating sources. -
Page 31: Warranty&Contact Us
There are our general terms for the warranty service,but we always encourage our customers to contact us if any issues,regardless of warranty terms. If you are experiencing an issue with Yaufey product,you can reach out to us at support@yaufey.com,we will dedicate our efforts to resolve it for you. - Page 32 @yaufey @yaufey YAUFEY @yaufey For FAOs and more information please visit: www.yaufey.com @yaufey (Scan the QR Code for Live Chat) We are expecting to see our products fulfill your lfe and hear your voice. Your satisfaction means a lot to us.
