YAUFEY PD606C User Manual

Commercial dehumidifier

Advertisement

Quick Links

Commercial Dehumidifier
Please read the manual carefully
before using the product
PD606C
USER MANUAL
www.yaufey.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD606C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for YAUFEY PD606C

  • Page 1 Commercial Dehumidifier Please read the manual carefully before using the product PD606C USER MANUAL www.yaufey.com...
  • Page 3 REQUESTING CUSTOMER SERVICE If there are any problems of the product, please contact Yaufey Customer Service at support@yaufey.com with your Purchase Order ID. We’ll help...
  • Page 4 BEFORE FIRST USE: To protect the product from any internal damages, please keep the product in the upright position throughout its journey. Please take out the product and leave it standing in the upright position for 24 HOURS before plugging it in.
  • Page 5: Table Of Contents

    Precautions for Use ..............01 Product Introduction ..............02 Operation Instructions...............03 Parts Description ...............06 Specifications ................07 Malfunction Codes ..............08 Safty Operations and Protection..........09 Mantainance and Repair ............11 Troubleshooting .................12 Warranty&Contact Us..............13 The graphics and functions provided in this manual maybe not the same as the actual product.
  • Page 6: Precautions For Use

    Safety Note: Before installing, operating and maintaining this machine, please read the safety precautions carefully. Please remove the package of the machine before use. Please keep it far away from children to avoid the risk of suffocation. Before connecting the machine to a power supply, please make sure the voltage is applicable.
  • Page 7: Product Introduction

    INTRODUCTION Product Introduction The dehumidifier is used to remove moisture from the air to maintain a proper room humidity. Beautiful, compact and easy-to-use, this dehumidifier is widely used in places with high humidity, such as scientific research institutes, medical and health clinics, commodity storage rooms, kitchens, bathrooms, archives, warehouses to prevent instruments, meters, telecommunications equipment, medicines, and materials from being damp, rusted, and moldy.
  • Page 8: Operation Instructions

    Turn up humidity Turn down humidity Power Button Timing Button Function Button Button Description 1. Power Button: In the power-off state, press this button to turn on the machine and vice versa (In the power-on state, the LED screen will light up). 2.
  • Page 9 Timing Setting In the power-on state, press the "Timing" button to enter the timing setting state. The timing indicator will light up and the dispaly will flash small number to show the time. In the timing setting state, press the "UP" or "Down"...
  • Page 10 Memory Function When power resumes, the machine will work at the same settings before power outage. Defrost Function When frost builds up on the evaporator coils, the compressor will cycle off and the fan will continue to run until the frost disappears. Temperature Protection Function When the ambient temperature is higher than the default temperature of 113℉, the system will activate high-temperature protection, the small...
  • Page 11: Parts Description

    Buckle Castors Note: This picture only shows the outline drawing of the dehumidifier. Other models may vary in shape and size. Please refer to the actual product.
  • Page 12: Specifications

    MODEL PD606C POWER SOURCE 120V ~60Hz RATED POWER 1000w RATED CURRENT 8.8A MOISTURE REMOVAL (65℉, 60%RH) 47 Pints/Day MOISTURE REMOVAL (80℉, 60%RH) 75 Pints/Day MOISTURE REMOVAL (86℉, 80%RH) 126 Pints/Day MOISTURE REMOVAL (95℉, 90%RH) 155 Pints/Day INPUT POWER (65℉, 60%RH) 515W INPUT CURRENT (65℉, 60%RH)
  • Page 13: Malfunction Codes

    3. When the code E2 appears, the operation of the machine will not be controlled by the operation panel. 4. If the malfunctions still exist, please don’t hesitate to contact Yaufey Customer Service email: support@yaufey.com...
  • Page 14: Safty Operations And Protection

    Place the drainage hose well when drain water conti- nuously so as to flow the water freely. If work in a cold temperature that could freeze the water, then the continuous drainage may not be applicable.
  • Page 16: Mantainance And Repair

    MANTAINANCE AND REPAIR Before cleaning or maintaining the machine, please unplug it from the power source. Please clean the machine at least once a month. Do not use detergent, steel wire ball, chemical treated dust removing cloth, gasoline, benzene, thinner or other solvents to clean the machine, as these items could damage the machine's body.
  • Page 17: Troubleshooting

    TROUBLESHOOTING Causes Troubleshooting Malfunctions 1. Power failure 1. Supply power again 2. Switch is not connected 2. Re-connect to power The dehumidifier 3. Plug is not inserted into 3. Insert plug into socket does not operate socket 4. Replace fuse 4.
  • Page 18: Warranty&Contact Us

    CONTACT US Warranty Yaufey offers a 12-month warranty to all of our products together with the original proof of purchase when a defect occured, including those newly purchased and unused, from Yaufey or through an authorized reseller, wholly or substantially, or as a result of faulty manufacturing parts, or workmanship during the Warranty Period.
  • Page 20 Yaufey Yaufey Yaufey www.yaufey.com Yaufey We are expecting to see our products fulfill your life and hear your voice. Your satisfaction means a lot to us. Please tag us if you share a snap on your social media. www.yaufey.com...
