Chicco 07079655470070 Instructions

PMS 2747 and PMS 186
INSTRUCTIONS:
IMPORTANT: Please also refer to the Owner's Manual that came with your product.
1
Make sure the Locking Tab is down in the
unlocked position. On the BACK of the Bassinet
insert the Diaper Caddy Locking Pin into the
Bassinet, as shown. Make sure the Locking Pin is
pushed firmly into place.
3
On the FRONT of the Bassinet, attach the Zipper at the top and zip it closed.
WARNING: DO NOT put objects in the Diaper Caddy that
may be harmful to your child. The combined weight of items
stored in caddy cannot exceed 5 lbs (2.3 kg). You must read and
understand Close To You Diaper Caddy instructions and the
Close To You Owner's Manual. If you do not understand these
instructions call Chicco at 1-877-424-4226.
Close To You Diaper Caddy
LOCKED
UNLOCKED
2
the bottom of the bassinet, pull the Locking Tab
towards you until it is up in the locked postion, flat
against the top of the Caddy.
1
While holding the Diaper Caddy flush against
SS0029E_02
