Delta Lockable Bike Hitch BH6002-PRO Assembly Instructions

Lockable
Bike Hitch
Assembly instructions
Place Bike Hitch in desired location
1
and mark one hole for drilling.
2 Drill hole using 1/4" bit.
IMPORTANT SAFETY NOTE
Wear eye protection when using power tools.
Insert 1/4" (6mm) diameter bolt through hole and tighten securely.
3
(Bolts are not included - length will vary with application)
4
Drill second hole using Bike Hitch's base as a guide.
Insert second bolt and tighten securely.
5
To prevent loosening, we recommend the use of nuts
with nylon inserts, thread locking uid, or lock washers.
WARNING
The Bike Hitch is designed to hold a bicycle only and has not been designed to support a rider
and should never be used with a person on the bike.
™
Alignment ring
(Pro model only)
