INSTRUCTIONS
ARMREST REPAIR
KIT
80994
BEFORE YOU BEGIN:
• Always wear proper safety
equipment when performing repairs.
• Ensure at your point of purchase
that this part fits your exact
vehicle configuration.
• Reference the appropriate service
manual for your vehicle. If you do
not have a service manual, and do
not have the training or experience
to perform the necessary
procedures correctly, seek the
services of a qualified technician.
NEED HELP?
Please call our Technical Support
team for assistance from our team of
certified automotive experts.
1-866-933-2911
© 2023 No reproduction in whole or in part without prior written approval.
80994_Instructions
RECOMMENDED
TOOLS
•
Razor blade or slotted screwdriver
• 7/32" drill bit
• Marker
•
Trim panel removal tool (optional)
• Butyl tape (optional)
•
Blanket (optional)
• Pliers (optional)
INSTRUCTIONS
STEP 1:
Remove door panel. Place on soft surface to
prevent damage. Remove water vapor barrier for
reuse. Protect butyl tape if not reapplying.
NOTE: Butyl tape may be necessary to
reattach barrier.
STEP 2:
Remove window switch.
STEP 3:
Remove the door pull retaining hardware.
Dorman Products, Inc. Corporate Office and Customer Service: 1-800-523-2492.
Disclaimer: It is impossible in these instructions to account for all possible circumstances or situations that you may experience when at-
tempting to install this product. Please consult with a qualified auto technician before attempting to perform any work you are not qualified to
do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor
Vehicle Safety Standards by the National Highway Traffic Safety Administration). Be sure that your work is performed in accordance with such
standards and that you do not disable any motor vehicle safety feature.
STEP 4:
Using the replacement as a guide, identify the
plastic welds that affix armrest to door panel.
STEP 5:
Remove the welds holding the armrest in place.
Using a flap disc, sand the welds flush. It is also
possible to drill the weld centers with a 7/32" drill
bit. Use a small slotted screwdriver to collapse
the weld edges into the centers.
