REMOVAL/INSTALL INSTRUCTIONS: REPLACEMENT RADIO BUTTONS
ATTENTION: Refer to the appropriate shop manual for your vehicle to obtain specific service procedures for this part. If you do not
have a service manual or have any reservations with this instruction set, please seek the services of a qualified technician. Also, please
pay special attention to all cautions and warnings included in the shop manual, and Read and follow all instructions carefully!
REMOVAL/INSTALL OF RADIO BUTTONS (Part# 76824)
General Tech Tips:

Work in a location that is clean & static-free (static discharge has the potential to permanently damage
electrical components).

Use plastic zip-lock bags or compartment trays to temporarily store small screws and other items that
may need disassembly from the radio. Labeling these containers with respect to their subassemblies
will make organization and re-assembly a lot easier.

A plastic pry tool is useful. It will not easily damage delicate trim like a screwdriver or metal pry bar

Upon disassembly of the button components, pay specific attention to the 'layering' of components as
this will be critical to the proper function of the replacement buttons during re-installation

Be aware of sharp edges from the metal enclosures of the radios
Common Tools Used:

Flat-head screwdrivers

Needle-nose pliers

3/16 Hex nut driver

1/8 Hex nut driver

Torx 15 bit driver

Socket wrench set
GM Vehicles 2003-2007
Please Wear Protective Eyewear!
No in or in part approval.
