Ram Mounts RAM Pod I Manual

Parts Index
* not to scale
Before installation, locate the best possible attachment point for (C) foot base, such as a seat bolt or any other existing screw, nut or bolt.
If desired, you may drill your own attachment point using a bolt, washer and nut, or with a sheet metal screw.
Pre-bend (A) flex rod to brace against
1
another object while mounted, such
as the center console of your vehicle.
Safety Precaution
Do not install this product near or over an airbag deployment area or in a location that obstructs the driver's vision or interferes with vehicle
operation. National Products, Inc does not assume responsibility or liability for any such personal injury, death or property damage.
To see more mounting options, visit rammount.com
rammount.com
1.800.497.7479
support@rammount.com
A
x 1
B
x 1
Assemble the seat base as shown. Make sure you have
2
(A) flex rod pre-bent to the desired angle before sliding on
(B) tube covering.
A
C
This document, including images, may not be reproduced partly or fully without the expressed written consent of National Products, Inc.
RAM
D
x 1
1/4"-20 x 1"
D
G
B
F
E
Pod I Vehicle Mount
® ™
C
x 1
E
G
F
x 1 x 1 x 1
1/4"-20 #10-24 x 3/4"
Locate attachment point and use
3
existing seat bolt and washer to
secure the foot base assembly.
H
RMR-INS-316-1
H
x 1
#10-24
