brondell BF100 Installation

Top Spout
Top Cap
Main Body
Escutcheon
Lock Washer
REPLACING THE BATTERY (with each filter change)
Replace the battery in the faucet LED indicator to reset the filter change reminder. Use the new CR2032 battery included
with your replacement filter set.
1. Under the Faucet Handle, locate the black rubber Battery Seat. Grasp it from the sides and pull down.
2. Remove the old battery by gently lifting the silver metal tab and sliding the battery out of the Battery Seat. Wait 30
seconds before inserting the new battery.
3. Insert the new CR2032 battery by sliding the battery under the silver tab, making sure that the "+" sign and CR2032 are
facing towards you.
4. Push the Battery Seat back up into the Faucet Handle.
1
Brondell has water filtration systems to suit any household size and kitchen configuration.
Questions about installation? Call our customer service department at 888-542-3355.
BF100 FILTERED WATER FAUCET INSTALLATION
& BATTERY REPLACEMENT
INSTALLING THE FAUCET
1. Unpack the faucet and insert the Top Spout into the Main Body by
2. Cut zip tie on the blue water connection tubing and unroll to straighten
3. Attach the Escutcheon to the Main Body by inserting the blue tubing
4. Install the faucet on top of the countertop or sink and feed the blue tubing
LED Indicator
Battery Seat
5. Install the Lock Washer and the Locking Nut the same way and tighten
CR2032
Battery
6. Pull the plastic tab out from the Battery Seat to activate the LED Indicator.
Counter Top
Plastic Washer
Locking Nut
1/4" Tube
(connected to faucet)
3
Visit us at brondell.com to see all of our water filter systems.
One-year Limited Warranty. Please visit brondell.com for more details.
pushing down until inserted, then screw the Top Cap clockwise until
secured in place.
tubing. Be careful not to cut the tube when removing the zip tie.
through the Escutcheon and pushing it all the way up until connected to
the Main Body.
through the hole to the cabinet below. Then slide the large Plastic Washer
as shown up through the blue tubing until snug against the bottom of the
countertop or sink hole.
until the Plastic Washer is holding the faucet assembly firmly in place.
The faucet is now installed!
The LED light will blink red once, blue once, and then will be ready to go.
4
For California Residents
CR2032 batteries contain Perchlorate Material - special
handling may apply.
Visit http://www.dtsc.ca.gov/hazardouswaste/perchlorate
for more information.
#18BF100-0605
