brondell BF200 Installation

BF200/BF400 Filtered Water Faucet Installation
Small Rubber Washer
Lock Washer
Locking Nut
Questions about installation? Call our customer service department at 888-542-3355 or visit brondell.com
Top Spout
Top Cap
Main Body
Escutcheon
Large Rubber Washer
Counter Top
Plastic Washer
1/4" Tube
(connected to faucet)
Installing the Faucet
1. Unpack the faucet and insert the Top Spout into the Main Body by
pushing down until fully inserted, then screw the Top Cap clockwise
until secured in place.
2. Cut zip tie on the blue water connection tubing and unroll to
straighten tubing. Be careful not to cut the tube when removing the
zip tie.
3. Install the Escutcheon (faucet base), curved lip side down, by
inserting the blue tubing through the Escutcheon and the Large
Rubber Washer and push both all the way up until adjacent to the
Main Body.
4. Install the faucet on top of the countertop or sink and feed the blue
tubing through the hole to the cabinet below. Slide the large Plastic
Washer and Small Rubber Washer as shown to the left up through the
blue tubing until snug against the bottom of the countertop or sink
hole.
5. Install the Lock Washer and the Locking Nut the same way and
tighten until the Plastic Washer and Small Rubber Washer are holding
the faucet assembly firmly in place. The faucet is now installed!
