Liberty Garden 710 Mounting Hardware Instructions

Liberty Garden Mounting Hardware Reference Chart
Required
Tools and
Washers
Electric Drill
Hammer Drill
Wood Drill Bit
Masonry Drill Bit
Lock Washer
Flat Washer
CAUTION: The minimum required insertion depth of a brick or masonry anchor sleeve is 1 inch.
Ensure the drill hole is deeper than the depth of the sleeve once the anchor is inserted. This will
prevent the wall mounted garden product from falling.
Note: Drill hole diameters may vary based on anchor sleeves, concrete screws and wood screw
manufacturer.
Check product recommendations before drilling holes
Wood Screw
5/16 " x 2 ½ " Long
Wood Drill Bit
1/4" Drill Bit
1/4" Pilot Hole
5/16"
®
Brick or Masonry Screw Brick or Masonry Anchor
5/16 " x 2 ½ " Long
Masonry Drill Bit
1/4" Drill Bit
1/4" Pilot Hole
5/16"
5/16 " x 2 ½ " Long
Not Applicable
Masonry Drill Bit
5/16" Drill Bit
5/16" Pilot Hole
5/16"
5/16"
