NIOSH WB-N-120-M User Instruction

User Instruction
For special fitting demand, N95 respirator WB-N-120-M, TC-84A-7284.
Warning
This respirator helps protect against certain particles. Misuse may result in sickness or death. For proper use, see supervisor,
User Instructions, or call 001 4697671124.
Company Name: WellBefore
Address: 11528 Harry Hines Blvd. Suite A102 Dallas TX USA 75229
Fax: 001 4697671124
Use For :
Provide protection against solid such those form processing minerals, iron ore, coal, flour, and certain substance. Liquid
or non-oil based particle from sprays that does not emit oil aerosols vapors.
USE LIMITATIONS:
1. Do NOT use the respirator or enter or stay in a contaminated area under the following circumstances:
• Atmosphere contains less than 19.5% oxygen
• Atmosphere contains oil aerosols if using N protection class respirator
• For protection against gases or vapors
• Contaminants or their concentrations are unknown or immediately dangerous to life or health
• Concentrations or contaminants exceed maximum use concentrations in applicable OSHA standards or applicable government regulations
or10 times the PEL (Permissible Exposure Limit), whichever is lower
• For sandblasting, paint-spray operations, asbestos
2. Do NOT modify or misuse the respirator.
3. Do NOT use the respirator with beards or other facial hair that interferes with direct contact between the face and the edge of the respirator, or
any other conditions that may prevent a good face-seal.
WARNING:
This respirator helps protect against certain contaminants. It may not eliminate the risk of contracting disease or infection. Misuse may result in
sickness or death. Materials which may come into contact with the wearer's skin could cause allergic reactions to susceptible individuals.
Before occupational use of this respirator, a written respiratory protection program must be implemented meeting all the local government requirements. In the
United States, employers must comply with OSHA 29 CFR 1910.134 which includes medical evaluation, training, and fit testing.
FOR MORE INFORMATION or assistance please contact with Manufacturer.
FITTING INSTRUCTIONS:
Follow these instructions each time respirator is worn.
1. Hold the respirator in one hand with the nosepiece at your fingertips, allowing the headbands to hang below your hand.
2. Press the respirator against your face with the nosepiece on the bridge of your nose.
3. Place the top band high on the back of your head. Move the bottom band over your head and position it below your ears.
4. Place your fingertips from both hands at the top of the metal nosepiece. Using two hands, mold the nose area to the
5. Fit-check the face-seal as follows:
WARNING: If you cannot achieve satisfactory fit, do NOT enter the contaminated area. See your Supervisor.
USE INSTRUCTIONS:
1. Failure to follow all instructions and limitations concerning the use of the respirator and/or failure to wear the respirator
2. Before use, the wearer must first be trained by the employer in the correct use of the respirator in accordance with
3. OSHA standards including 29 CFR 1910.134 (e) (5) and CSA standard Z94.4-93 require that the wearer be fit-tested.
4. Discard the respirator and replace with a new one if:
5. Leave the contaminated area if dizziness, irritation or other distress occurs.
6. This respirator has been tested and small punctures within ultrasonic welding areas are normal and do not interfere with
the respirator compliance with Part 84 approval requirements: (A) filtering facepieces are to be inspected prior to each use
to assure there are no holes in a breathing zone other than the punctures within ultrasonic welding areas and no damage has
occurred, and (B) enlarged holes resulting from ripped or torn filter material within ultrasonic welding areas punctures are
considered damage.
Special Instruction Section:
This respirator offers nuisance level relief from (type of odor (such as organic vapors)) that are below the permissible exposure limit (PEL) . Nuisance level
refers to concentrations not exceeding the OSHA PEL or other government occupational exposure limits, whichever is lower.
The model WB-N-120-M filtering facepiece respirator has been manufactured by approval holder Suzhou Sanical for private label WellBefore under TC-84A-
7284.
shape of your nose by pushing inward while moving your fingertips down both sides of the nosepiece.
.Warning: Pinching the nosepiece using one hand may result in improper fit and less effective respirator performance.
Use two hands.
• Place both hands over the respirator without disturbing its position
•Exhale sharply, if you detect air-leaks, readjust the nosepiece and/or head straps position.
for the whole duration of exposure to contaminants can seriously reduce the performance characteristics of the respirator
and lead to illness, injury or death.
applicable safety and health standards.
• Excessive clogging of the respirator causes breathing difficulty.
• The respirator becomes damaged.
WB-N-120-MUI A/0 Date: Apr 25, 2021
