Dynacord ALPHA SYSTEM Brochure page 19

It is remarkable in its class for
the very high sound pressure
levels it is capable of achieving as
well as its outstanding audio
performance.
The wide range of mounting accesso-
ries available for the enclosure and
its tastefully understated styling
permit its convenient use even in
critical applications in the fixed
installation sector.
The housing is made from ABS
and capable of withstanding the
roughest handling during trans-
portation and use. The D8's bass
and midrange is the responsibility
of the DND8200-8 low-distortion
neodymium woofer. The integration
into the baffle of the symmetrically
radiating Constant Directivity high
frequency horn, with its nominal
radiation angle of 90° x 90° (hori-
zontal x vertical) and Electro-Voice
DH3 driver, is CAD-optimized.
With power handling of 250 W (rated)
and 1,000 W (peak), a maximum
SPL of 124 dB and a frequency range
of 65Hz - 20 kHz, the D8 performs
outstanding service not only as a
full-range cabinet but also as the
mid / high component of active and
passive satellite systems of superior
quality. The crossover is optimized
D 8
to achieve a long throw and a very
even sound pattern, permitting the
use of the D8 even in unfavorable
acoustic environments.
The loudspeaker components are
guarded by thermo-switches and
halogen protectors against thermal
overload.
The front is clad in black acoustic
foam with a robust, powder-coated
steel grille. The SPEAKON sockets
on the connection panel are re-
cessed. The enclosure is trapezoidal
in shape, making it suitable also
for monitoring applications.
D 8W
AND
19
