Dynacord ALPHA SYSTEM Brochure page 103

CXM 15 TECHNICAL SPECIFICATIONS
CXM 15
Type / Name
Cabinet Coaxial Monitor
Confi guration Passive 2-Way
or Biamped Mode
Components 15" / 1,4"
Impedance
Rated Power
Peak Power
SPL 1W / 1m
Max. SPL 1m
Freq. Range 100 Hz - 18 kHz
Coverage
Dimensions (WxHxD) mm 600 x 334 x 412
Net. Weight
AM 12 TECHNICAL SPECIFICATIONS
AM 12
Type / Name
Cabinet
Confi guration
Components
Impedance
Rated Power
Peak Power
SPL 1W / 1m
Max. SPL 1m
Freq. Range 80 Hz - 18 kHz
Coverage
531 x 355 x 344
Dimensions (WxHxD) mm
Net. Weight
CXM 15 CXM 15W
Coaxial Monitor
Passive 2-Way
or Biamped Mode
15" / 1,4"
8 Ohms 8 Ohms
450 W 450 W
1800 W 1800 W
102 dB 102 dB
135 dB 135 dB
100 Hz - 18 kHz
60° x 60° 60° x 60°
600 x 334 x 412
19 kg 19 kg
Monitor
Powered
2-Way
12" / 1"
---
60 W HF
300W LF
---
100 dB
125 dB
90° x 40°
21 kg
T S
ECHNICAL PECIFICATIONS
103
