Dynacord ALPHA SYSTEM Brochure page 118

A G
PPLICATION UIDE
COBRA 4 APPLICATION GUIDE
COBRA 4 LINE-ARRAY SYSTEM FOR MID-SIZED VENUES
COBRA 4 LINE-ARRAY SYSTEM FOR LARGER VENUES
118
Confi guration Active 4-Way
4x Cobra-4 Far,
Cabinet Types
4x Cobra Top,
8x Cobra PWH
5x H 5000
Amplifi ers
5x RCM 26
Controllers
6x 8-pole lomg,
Cables
8x 8-pole short
Accessories Rigging Straps CSST,
CSSM
Horizontal 2x 120°
Coverage
Total Amp Power 10x 2500 W = 25 kw
Typical Distance 40 - 80 m
Options
Comments
Confi guration Active 4-Way
4x Cobra-4 Far,
Cabinet Types
8x Cobra Top,
12-16x Cobra PWH
8x LX 3000
Amplifi ers
4x DSP 260
Controllers
or DSP 600
Cables 12x 8-pole long,
16x 8-pole short
-
Accessories
2x 120°
Horizontal
Coverage
Total Amp Power 4x 2100 W
+ 12x 1800 W= 30kw
40 - 80m
Typical Distance
FG 600 (Grid)
Options
System can be split into
Comments
two separate Systems
