Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
XVS95CRG
XVS95CRGC
LIT-11626-29-46
B33-28199-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bolt R-Spec XVS95CRG 2015 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yamaha Bolt R-Spec XVS95CRG 2015

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XVS95CRG XVS95CRGC LIT-11626-29-46 B33-28199-11...
  • Page 2 EAU10043 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
  • Page 4: Important Manual Information

    Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10194 XVS95CRG / XVS95CRGC OWNER’S MANUAL ©2015 by Yamaha Motor Corporation, U.S.A. 1st edition, August 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.
  • Page 6: Table Of Contents

    Table of contents Location of important labels... 1-1 For your safety – pre-operation Checking the brake lever free checks ..........5-1 play..........7-17 Safety information......2-1 Brake light switches ..... 7-18 Operation and important riding Checking the front and rear brake Description ........
  • Page 7 Storage ..........8-3 Specifications........9-1 Consumer information ....10-1 Identification numbers....10-1 Reporting safety defects ....10-3 Motorcycle noise regulation ..10-4 Maintenance record ......10-5 YAMAHA MOTOR CORPORATION, U.S.A. 2015 AND LATER MODEL STREET & DUAL-PURPOSE MOTORCYCLE LIMITED WARRANTY .......10-7 YAMAHA EXTENDED SERVICE (Y.E.S.) ........10-9 Index ..........11-1...
  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 Location of important labels 1 California only 2 California only VACUUM HOSE ROUTING EMISSION HOSE ROUTING PRESS. SENSOR THROTTLE BODY FUEL TANK ATMOSPHERE CANISTER INTAKE MANIFOLD 34B-21684-00 5RU-21686-00 WARNING TIRE INFORMATION This unit contains high pressure nitrogen gas. Col d t i r e no r m al p r e ssu r e sh o uld be s et as fo l l ow s.
  • Page 10: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU40959 out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 11 Safety information  Many accidents involve inexperi-  The use of a jacket, heavy boots, • Always signal before turning or enced operators. In fact, many op- changing lanes. Make sure that trousers, gloves, etc., is effective erators who have been involved in other motorists can see you.
  • Page 12 To Yamaha accessories, which are avail- instability. avoid the possibility of an accident, use able only from a Yamaha dealer, have  Shifting weights can create a sud- extreme caution when adding cargo or been designed, tested, and approved den imbalance.
  • Page 13  Never install accessories or carry for Yamaha vehicles. Yamaha is not in passed by large vehicles. a position to test the products that cargo that would impair the per- •...
  • Page 14 Safety information may not be appropriate. Refer to page the location for the straps carefully 7-15 for tire specifications and more in- so the straps will not rub against formation on replacing your tires. painted surfaces during transport.  The suspension should be com- Transporting the Motorcycle pressed somewhat by the tie- Be sure to observe following instruc-...
  • Page 15: Description

    Description EAU10411 Left view 1. Headlight (page 7-28) 2. Owner’s tool kit (page 7-2) 3. Shock absorber assembly spring preload adjusting ring (page 4-14) 4. Fuses (page 7-27) 5. Engine oil drain bolt (page 7-11) 6. Shift pedal (page 4-8) 7.
  • Page 16: Right View

    Description EAU10421 Right view 1. License plate light (page 7-30) 9. Rear brake light switch (page 7-18) 2. Brake/tail light (page 7-29) 10.Brake pedal (page 4-8) 3. Battery (page 7-25) 11.Shock absorber assembly spring preload adjusting ring (page 4-14) 4. Rear brake fluid reservoir (page 7-19) 5.
  • Page 17: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 4-7) 2. Left handlebar switches (page 4-6) 3. Multi-function meter unit (page 4-3) 4. Front brake fluid reservoir (page 7-19) 5. Right handlebar switches (page 4-6) 6. Brake lever (page 4-8) 7.
  • Page 18: Instrument And Control Functions

    Instrument and control functions EAU55831 EAU10542 EAU62271 Main switch (Parking) All electrical circuits are supplied with The hazard lights and turn signal lights power; the meter lighting, taillight, li- can be turned on, but all other electri- cense plate light and position lights cal systems are off.
  • Page 19: Indicator Lights And Warning Lights

    6. Engine trouble warning light “ ” confirming that the oil level is correct come on for a few seconds and then (see page 7-11), have a Yamaha dealer go off. EAU11022 check the vehicle. Turn signal indicator light “...
  • Page 20: Multi-Function Meter Unit

    Multi-function meter unit level warning light will flash repeatedly. This warning light will come on when If this occurs, have a Yamaha dealer the key is turned to “ON” and the start check the vehicle. switch is pushed, but this does not in- dicate a malfunction.
  • Page 21 Instrument and control functions  a clock Odometer, tripmeters, fuel reserve In normal operation, push the “SE-  a self-diagnosis device tripmeter and clock LECT” switch to change the display between the odometer “ODO”, tripme- ters “TRIP 1” and “TRIP 2”, and the ...
  • Page 22 If the display indicates any error codes, 4. Push the “SELECT” switch to set note the code number and have a the minutes. Yamaha dealer check the vehicle. 5. Push the “SELECT” switch for one second to start the clock.
  • Page 23: Handlebar Switches

    Instrument and control functions Right EAU1234H EAU12461 Handlebar switches Turn signal switch “ ” To signal a right-hand turn, push this Left switch to “ ”. To signal a left-hand turn, push this switch to “ ”. When released, the switch returns to the cen- ter position.
  • Page 24: Clutch Lever

    Instrument and control functions See “Multi-function meter unit” on EAU41701 EAU12822 The engine trouble warning light will Clutch lever page 4-3 for detailed information. come on when the key is turned to “ON” and the start switch is pushed, but this does not indicate a malfunc- tion.
  • Page 25: Shift Pedal

    Instrument and control functions EAU12872 EAU12892 EAU12944 Shift pedal Brake lever Brake pedal 1. Shift pedal 1. Brake lever 1. Brake pedal 2. Neutral position The brake lever is located on the right The brake pedal is located on the right The shift pedal is located on the left side of the handlebar.
  • Page 26: Fuel Tank Cap

    Instrument and control functions 2. Turn the key counterclockwise to EAU13125 EAU13222 Fuel tank cap Fuel the original position, remove it, Make sure there is sufficient gasoline in and then close the lock cover. the tank. EWA10882 WARNING The fuel tank cap cannot be installed unless the key is in the lock.
  • Page 27 WARNING as well as to the exhaust system. Gasoline is poisonous and can Your Yamaha engine has been de- cause injury or death. Handle gaso- signed to use regular unleaded gaso- line with care. Never siphon gasoline line with a pump octane number by mouth.
  • Page 28: Fuel Tank Breather/Overflow Hose

    Instrument and control functions  Make sure that the fuel tank EAU48792 EAU13434 Fuel tank breather/overflow Catalytic converter breather/overflow hose is routed hose This model is equipped with a catalytic through the clamp. converter in the exhaust system. EWA10863 WARNING The exhaust system is hot after op- eration.
  • Page 29: Steering Lock

    Instrument and control functions To unlock the steering ECA10702 EAU55663 Steering lock NOTICE The steering lock is located on the right Use only unleaded gasoline. The use side of the vehicle between the upper of leaded gasoline will cause unre- and lower steering brackets.
  • Page 30: Seat

    Instrument and control functions EAU66400 Seat To remove the seat 1. Remove panel A. (See page 7-9.) 2. Remove the bolt. 1. Projection 1. Rubber damper 2. Seat holder Tightening torque: 2. Place the seat in the original posi- Seat fitting bolt: tion.
  • Page 31: Adjusting The Shock Absorber Assemblies

    Take the shock Maximum (hard): maximum or minimum settings. 4 notch(es) in direction (a)* absorber assembly to a Yamaha Adjust the spring preload as follows. * With the adjusting ring fully turned dealer for any service. in direction (b)
  • Page 32: Sidestand

    EAU15306 EAU68280 Sidestand Ignition circuit cut-off system Yamaha dealer repair it if it does not The sidestand is located on the left The ignition circuit cut-off system function properly. side of the frame. Raise the sidestand...
  • Page 33 Instrument and control functions WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the start/engine stop switch is set to “ ”. dealer check the system before riding.
  • Page 34: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended oil to specified level. 7-11 • Check vehicle for oil leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 35 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-14, 7-22 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-21 •...
  • Page 36 For your safety – pre-operation checks ITEM CHECKS PAGE • Check operation of ignition circuit cut-off system. 4-15 Sidestand switch • If system is not working correctly, have Yamaha dealer check vehicle.
  • Page 37: Operation And Important Riding Points

     a lean angle sensor to stop the en-  The transmission is in the neutral understand, ask your Yamaha dealer. gine in case of a turnover. In this EWA10272 position.
  • Page 38: Shifting

    NOTICE neutral position. The neutral indi-  Even with the transmission in cator light should come on. If not, ask a Yamaha dealer to check the the neutral position, do not electrical circuit. coast for long periods of time 3. Start the engine by sliding the with the engine off, and do not switch toward “...
  • Page 39: Engine Break-In

    Operation and important riding points 4. At the recommended shift points 3. Shift the transmission into the EAU16842 Engine break-in shown in the following table, close neutral position when the motor- There is never a more important period the throttle, and at the same time, cycle almost completely...
  • Page 40: Parking

    If any engine trouble should occur WARNING during the engine break-in period,  Since the engine and exhaust immediately have a Yamaha dealer system can become very hot, check the vehicle. park in a place where pedestri- ans or children are not likely to touch them and be burned.
  • Page 41: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.
  • Page 42: Owner's Tool Kits

    Owner’s tool kits  If you do not have the tools or ex- perience required for a particular job, have a Yamaha dealer per- form it for you.  Install the owner’s tool box with the “INSIDE” mark facing inward.
  • Page 43: Periodic Maintenance Chart For The Emission Control System

     From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months.  Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the ser- vice.
  • Page 44 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 45: General Maintenance And Lubrication Chart

    Periodic maintenance and adjustment EAU67550 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months...
  • Page 46 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 47 Front and rear √ √ √ √ √ √ 24 * • Check operation. brake switches • Apply Yamaha cable lubricant or √ √ √ √ √ √ 25 * Control cables other suitable cable lubricant thoroughly. • Check operation.
  • Page 48 Periodic maintenance and adjustment EAU17651  Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...
  • Page 49: Removing And Installing The Panel

    The panel shown needs to be removed checked periodically, preferably by a to perform some of the maintenance Yamaha dealer. Since heat and depos- jobs described in this chapter. Refer to its will cause any spark plug to slowly this section each time the panel needs erode, they should be removed and to be removed and installed.
  • Page 50: Canister (For California Only)

    Periodic maintenance and adjustment EAU19682 Specified spark plug: Canister (for California only) NGK/CPR7EA-9 If a torque wrench is not available when installing a spark plug, a good Before installing a spark plug, the THROTTLE BODY FUEL TANK estimate of the correct torque is 1/4– spark plug gap should be measured 1/2 turn past finger tight.
  • Page 51: Engine Oil And Oil Filter Cartridge

    Periodic maintenance and adjustment 5. If the engine oil is at or below the EAU47114 Engine oil and oil filter car- minimum level mark, add suffi- The engine oil should be between the tridge cient oil of the recommended type minimum and maximum level marks.
  • Page 52 Periodic maintenance and adjustment An oil filter wrench is available at a Yamaha dealer. 5. Apply a thin coat of clean engine oil to the O-ring of the new oil filter cartridge. 1. Engine oil drain bolt 1. Torque wrench 2.
  • Page 53: Replacing The Air Filter Element

     In order to prevent clutch slip- correct, immediately turn the engine off and have a Yamaha dealer check page (since the engine oil also the vehicle. lubricates the clutch), do not mix any chemical additives.
  • Page 54: Checking The Throttle Grip Free Play

    Measure the throttle grip free play as and/or engine noise. To prevent this shown. from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Air filter element 3.
  • Page 55: Tires

    Operation of this vehicle with im- cause an accident. the sidewall is cracked, have a Yamaha proper tire pressure may cause se- dealer replace the tire immediately. vere injury or death from loss of control.
  • Page 56: Cast Wheels

    Periodic maintenance and adjustment have a Yamaha dealer replace EWA10462 EAU21963 Cast wheels WARNING the tire immediately. Brakes, To maximize the performance, durabil- tires and related wheel parts re- The front and rear tires should be of ity, and safe operation of your vehicle,...
  • Page 57: Adjusting The Clutch Lever Free Play

    The clutch lever free play should mea- brake lever end. If there is free play, rection (b). sure 5.0–10.0 mm (0.20–0.39 in) as have a Yamaha dealer inspect the shown. Periodically check the clutch brake system. lever free play and, if necessary, adjust...
  • Page 58: Brake Light Switches

    1. Brake pad wear indicator groove adjusted by a Yamaha dealer. Each front brake pad is provided with Turn the rear brake light switch adjust- wear indicator grooves, which allow...
  • Page 59: Checking The Brake Fluid Level

    Rear brake EAU22582 Checking the brake fluid level peared, have a Yamaha dealer replace Before riding, check that the brake fluid the brake pads as a set. is above the minimum level mark. Check the brake fluid level with the top...
  • Page 60: Changing The Brake Fluid

    EAU22733 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the further riding. may deteriorate, causing leak- brake fluid at the intervals specified in age.
  • Page 61: Drive Belt Slack

    To check the drive belt slack damaged or does not move smoothly, 1. Place the vehicle on the side- have a Yamaha dealer check or re- stand. place it. WARNING! Damage to the 2. Note the current position of the...
  • Page 62: Checking And Lubricating The Throttle Grip And Cable

    In pedals should be checked before each addition, the cable should be lubricat- ride, and the pedal pivots should be lu- ed by a Yamaha dealer at the intervals bricated if necessary. specified in the periodic maintenance Brake pedal chart.
  • Page 63: Checking And Lubricating The Brake And Clutch Levers

    EWA10732 Clutch lever WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.
  • Page 64: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- face and hold it in an upright posi- fork does not operate smoothly, ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, have a Yamaha dealer check or re- specified in the periodic maintenance securely support the vehicle so pair it.
  • Page 65: Checking The Steering

    If any free This model is equipped with a VRLA smoothly, have a Yamaha dealer play can be felt, have a Yamaha (Valve Regulated Lead Acid) battery. check the wheel bearings. dealer check or repair the steer- There is no need to check the electro- ing.
  • Page 66 To charge the battery charge it if necessary. Have a Yamaha dealer charge the bat- 3. Fully charge the battery before in- stallation. NOTICE: When install- tery as soon as possible if it seems to have discharged.
  • Page 67: Replacing The Fuses

    Periodic maintenance and adjustment EAU55673 Replacing the fuses The main fuse, the fuel injection sys- tem fuse, and the fuse box, which con- tains the fuses for the individual circuits, are located under the owner’s tool box behind panel A. (See page 7-9.) 1.
  • Page 68: Replacing The Headlight Bulb

    4. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 1. Headlight bulb cover 2. Headlight coupler 1. Do not touch the glass part of the bulb.
  • Page 69: Brake/Tail Light

    6. Install the headlight unit by install- position, and then secure it with ing the screws. the bulb holder. 7. Have a Yamaha dealer adjust the 5. Install the bulb cover, and then headlight beam if necessary. connect the coupler.
  • Page 70: Replacing A Turn Signal Light Bulb

    Replacing a turn signal light License plate light bulb If the license plate light does not come on, have a Yamaha dealer check the 1. Remove the turn signal light lens electrical circuit or replace the bulb. by removing the screws.
  • Page 71: Supporting The Motorcycle

    However, should your motorcycle To service the front wheel require any repair, take it to a Yamaha 1. Stabilize the rear of the motorcy- dealer, whose skilled technicians have cle by using a motorcycle stand...
  • Page 72 Periodic maintenance and adjustment heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or prop- erty damage. 7-32...
  • Page 73: Troubleshooting Chart

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 74: Motorcycle Care And Storage

    Some models are equipped with matte colored finished parts. Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE used. A rusty exhaust pipe may go un-...
  • Page 75 Motorcycle care and storage off any detergent residue using shield. Test the product on a plenty of water, as it is harmful small hidden part of the wind- Salt sprayed on roads in the winter to plastic parts. shield to make sure that it does may remain well into spring.
  • Page 76: Storage

    Contaminants on the brakes or tires of the presence of ammonia) can cause loss of control.  Consult a Yamaha dealer for ad- and areas where strong chemi-  Make sure that there is no oil or vice on what products to use.
  • Page 77 Motorcycle care and storage 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.
  • Page 78: Specifications

    Specifications Dimensions: Fuel: Compression ratio: 9.0 : 1 Overall length: Recommended fuel: Starting system: 2295 mm (90.4 in) Regular unleaded gasoline (Gasohol [E10] Electric starter Overall width: acceptable) Lubrication system: 775 mm (30.5 in) Fuel tank capacity: Wet sump Overall height: 12 L (3.2 US gal, 2.6 Imp.gal) Engine oil: 1160 mm (45.7 in)
  • Page 79 Specifications 2nd: Tire air pressure (measured on cold Wheel travel: 2.063 (33/16) 120 mm (4.7 in) tires): 3rd: Rear suspension: Front: 1.579 (30/19) Type: 225 kPa (2.25 kgf/cm², 33 psi) 4th: Swingarm Rear: 1.259 (34/27) Spring: 250 kPa (2.50 kgf/cm², 36 psi) 5th: Coil spring Front wheel:...
  • Page 80 Specifications Rear turn signal light: 21.0 W × 2 License plate light: 5.0 W × 1 Meter lighting: EL (Electroluminescent) Neutral indicator light: High beam indicator light: Oil level warning light: Turn signal indicator light: Fuel level warning light: Engine trouble warning light: Fuse(s): Main fuse: 40.0 A...
  • Page 81: Consumer Information

    Vehicle identification number ed when registering the vehicle with the authorities in your area and when EAU26442 Engine serial number ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number ENGINE SERIAL NUMBER: The vehicle identification number is 1.
  • Page 82 This information will it for reference when ordering a new illustration. This label shows specifica- be needed when ordering spare parts key. tions related to exhaust emissions as from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...
  • Page 83: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immedi- ately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 84: Motorcycle Noise Regulation

    Consumer information EAU26561 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
  • Page 85: Maintenance Record

    Consumer information EAU26633 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 86 Consumer information Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...
  • Page 87: Yamaha Motor

    Consumer information EAU61801 YAMAHA MOTOR CORPORATION, U.S.A. 2015 AND LATER MODEL STREET & DUAL-PURPOSE MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this ENGINE each new Yamaha motorcycle purchased from an warranty shall be to:...
  • Page 88: Warranty

    CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.
  • Page 89: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 90 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 91: Index

    Index Fuel level warning light......4-2 Fuel tank breather/overflow hose ..4-11 Air filter element, replacing....7-13 Panel, removing and installing....7-9 Fuel tank cap.......... 4-9 Parking............ 6-4 Fuses, replacing........7-27 Part locations.......... 3-1 Battery ..........7-25 Pass switch..........4-6 Brake and clutch levers, checking and Handlebar switches .......
  • Page 92 Index Turn signal light bulb, replacing....7-30 Turn signal switch ........4-6 Valve clearance........7-14 Vehicle Emission Control Information label ............10-2 Vehicle identification number ....10-1 Warranty, extended ......10-9 Warranty, limited........10-7 Wheel bearings, checking.....7-25 Wheels ..........7-16 11-2...
  • Page 93 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 94 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2015.10-0.3×1 CR...
