Nokia ONT XS-010X-R Quick Reference Manual

1. Product Overview
The Nokia Optical Network Terminal (ONT) XS-010X-R ONT is
designed to cater to residential customer requirements and offers
data services to the subscriber through fiber to the home (FTTH) or
fiber to the premises (FTTP) applications.
The Nokia ONT XS-010X-R is an ONT suitable for indoor deployments
and is compliant with ITU-T G.9807.1, G.988 supporting a line rate of
both 10 Gb/s upstream and downstream.
This ONT offers data, voice, and video services to the subscriber
through FTTH or fiber to the premises (FTTP) applications. The ONT
XS-010X-R supports standard triple play services: voice, video and
high-speed internet access to support home networking.
With XGS PON as the uplink interface, the ONT XS-010X-R is also
compliant with the standard optical network unit (ONU) management
and control interface (OMCI) definition. The ONT XS-010X-R can be
managed from a remote site and supports the full range of fault,
configuration, accounting, performance, and security (FCAPS)
functions.
A. Technical Specifications
Width: 135 mm (5.31 in)
Height: 30 mm (1.19 in)
Depth: 135 mm (5.31 in)
Weight: 0.25 kg (0.5 lb)
Desk or wall mount
Power consumption:
• Standby mode: 4.3 W
• Typical mode: 7.5 W
© 2023 Nokia. Nokia Confidential Information. Use subject to agreed restrictions on disclosure and use.
If you have received this document in error, do not use or copy this document for any purpose nor disclose its contents to any other person.
Nokia ONT XS-010X-R Quick Reference Guide
B. Manufacturer Information
For Products Purchased in EU/EAA Countries
The products are manufactured and imported by Nokia Solutions and
Networks Oy.
Karakaari 7, 02160 Espoo, Finland.
Nokia is a registered trademark of Nokia Corporation.
For Products Purchased in the United States
The products are imported by Nokia of America Corporation.
Offices: https://www.nokia.com/contact-us/offices/#north-
•
america
Support: https://www.nokia.com/networks/business-support/
•
Other contacts:
•
Please contact your Internet Services Provider in case of questions
on the product.
2. Safety Guidelines
ALWAYS READ THE PRODUCT GUIDE BEFORE SET UP OR USE OF THE
PRODUCT. IT IS YOUR RESPONSIBILITY TO FAMILIARIZE YOURSELF
WITH THE PRODUCT GUIDE AND WARNINGS, AND TO USE A PRODUCT
PROPERLY. CONTACT YOUR INTERNET SERVICES PROVIDER FOR
FURTHER QUESTIONS.
Warning - Risk of electric shock or fire
Connect the Product power adaptor or cord to the right supply
voltage (for example, 230V in Europe, Turkey, Ukraine, 120V AC
in US, 230V in Australia and New Zealand, 230V in South Africa, 220V
in Russia, Morocco).
The socket-outlet shall be easily accessible.
Pay attention to the power load of the electrical outlet and possible
extension cord. An overburdened power outlet or damaged cords
and plugs may cause electric shock or fire. Check the power cords
regularly. If you find any damage, replace the cord immediately.
Do not connect the plug into an extension cord, receptacle, or other
outlet unless the plug can be fully inserted with no part of the blades
exposed.
Leave adequate space for heat dissipation to avoid any damage
caused by overheating the Product. Do not cover the Product or its
ventilation holes. Blocking the ventilation holes may cause fire.
Use the power adapter provided with your Product and do not fasten
the power cable to building surfaces. Ensure the cable can move
freely. Do not place heavy objects on the cable.
Do not use the Product outside, and make sure all the connections
are indoors.
CID213892
https://www.nokia.com/contact-us/
3TN-00666-AAAA-TCZZB
Issue 1, February 2024
