Nokia ONT XS-2426G-B Quick Reference Manual

Nokia ONT XS-2426G-B Quick Reference Guide
1. Product Overview
The Nokia ONT XS-2426G-B is the solution for home networking that
is delivered by 10 Gigabit symmetrical Passive Optical Network (XGS-
PON). The device has built-in concurrent dual-band Wi-Fi® 802.11
b/g/n/ax and 802.11a/n/ac/ax networking with triple play
capabilities that include voice, video and data. The XS-2426G-B
supports Wi-Fi EasyMesh™, to create a whole home mesh network.
The XS-2426G-B includes the Nokia WiFi Mesh Middleware which
ensures the best possible Wi-Fi performance. The end-user
experience is enhanced by the service provider's Wi-Fi management
capabilities in the cloud and
intuitive home user support using
the Nokia WiFi mobile app. The XS-
2426G-B also supports application
containers, that allow introducing
new services, from cybersecurity to
entertainment to productivity.
The XS-2426G-B is a dual-band Wi-
Fi 6 mesh system with Wi-Fi Alliance
certified Wi-Fi EasyMesh, enhanced
by Nokia value added features. The
Nokia WiFi Mesh Middleware creates
a self-healing, self-optimizing
network and includes intelligent
channel selection, band steering,
client steering and backhaul
management to provide the best
Wi-Fi performance.
A. Technical Specifications
Physical specifications
Specification Measurement
Height 226 mm (8.9 in)
Width 85 mm (3.3 in)
Depth 160 mm (6.3 in)
Weight EU version: 900 g (1.98 lb)
US version: 1200 g (2.65 lb)
Power consumption
Variant
Standby Mode
EU 10.2 W
US 10.2 W
© 2022 Nokia. Nokia Confidential Information. Use subject to agreed restrictions on disclosure and use.
If you have received this document in error, do not use or copy this document for any purpose nor disclose its contents to any other person.
Power Consumption
Typical Mode
14.9 W
21.6 W
Installation
Desk mountable
•
Wall mountable with bracket
•
B. Manufacturer Information
For Products Purchased in EU/EAA Countries
The products are manufactured and imported by Nokia Solutions and
Networks Oy.
Karakaari 7, 02160 Espoo, Finland.
Nokia is a registered trademark of Nokia Corporation.
For Products Purchased in the United States
The products are imported by Nokia of America Corporation.
Offices: https://www.nokia.com/contact-us/offices/#north-
•
america
Support: https://www.nokia.com/networks/business-support/
•
Other contacts: https://www.nokia.com/contact-us/
•
Please contact your Internet Services Provider in case of questions
on the product.
2. Safety Guidelines
ALWAYS READ THE PRODUCT GUIDE BEFORE SET UP OR USE OF THE
PRODUCT. IT IS YOUR RESPONSIBILITY TO FAMILIARIZE YOURSELF
WITH THE PRODUCT GUIDE AND WARNINGS, AND TO USE A PRODUCT
PROPERLY. CONTACT YOUR INTERNET SERVICES PROVIDER FOR
FURTHER QUESTIONS.
Warning - Risk of electric shock or fire
Connect the Product power adaptor or cord to the right supply
voltage (for example, 230V in Europe, Turkey, Ukraine, 120V AC
in US, 230V in Australia and New Zealand, 230V in South Africa, 220V
in Russia, Morocco).
The socket-outlet shall be easily accessible.
Pay attention to the power load of the electrical outlet and possible
extension cord. An overburdened power outlet or damaged cords
and plugs may cause electric shock or fire. Check the power cords
regularly. If you find any damage, replace the cord immediately.
Do not connect the plug into an extension cord, receptacle, or other
outlet unless the plug can be fully inserted with no part of the blades
exposed.
Leave adequate space for heat dissipation to avoid any damage
caused by overheating the Product. Do not cover the Product or its
ventilation holes. Blocking the ventilation holes may cause fire.
Use the power adapter provided with your Product and do not fasten
the power cable to building surfaces. Ensure the cable can move
freely. Do not place heavy objects on the cable.
CID 212398
3FE-49546-AAAA-TCZZB
Issue 1, March 2022
