SERVICE MANUAL
HUD21NK
CONTENTS
1
MODEL
PAGE
2
2
2
3
3-5
5
6
7
8
Advertisement
Table of Contents
Related Manuals for Hyundai HUD21NK
Summary of Contents for Hyundai HUD21NK
-
Page 1: Table Of Contents
HYUNDAI HUD21NK MODEL CONTENTS PAGE X-Ray RADIATION PRECAUTION ………………………………………………………………………………………. SAFETY PRECAUTION ……………………………………………………………………………………………….….. PRODUCT SAFETY NOTICE …………………………………………………………………………………………….. CHASSIS ADJUSTMENT…………………………………………………………………………………………………. COMPLETE MACHINE GENERAL ADJUSTMENT……………………………………………………………………. NOTES……………………………………………………………………………………………………………………… COLOUR PURITY AND CONVERGENCE ADJUSTMENT ………………………………...………………………… BLOCK DIAGRAM ………………………………………………………………………………………………………… WIRE DIAGRAM …………………………………………………………………………………………………………… SCHEMATIC DIAGRAM…………………………………………………………………………………………………… SPECIFICATIONS………………………………………………………………….………………………………..…… SERVICE MANUAL... -
Page 2: X-Ray Radiation Precaution
CAUTION Before serving the chassis, read the "X-Ray Radiation Precaution", "Safety Precaution" and "Product Safety Notice" on page 2 of this manual. X-RAY RADIATION PRECAUTION 1. Excessive high voltage can produce potentially hazardous X-Ray Radiation. To avoid such hazards, the high voltage must not be above the specified limit. -
Page 3: Chassis Adjustment
CHASSIS ADJUSTMENT 1. B+ voltage adjustment 1-1Connect 220V AC 50Hz to CN601 and switch on power switch SW601; 1-2Test the voltage with digital voltage meter between two terminals of C625; 1-3Adjust VR601 to obtain +110V+/-0.5V reading on the digital voltage meter. 2. - Page 4 4. PAL system vertical pincushion adjustment 4-1 Receive PAL system cross hatch pattern signal; 4-2 Press 'factory' key one time, go to system parameter adjustment menu; 4-3 Press 'MENU' key, go to horizontal and vertical parameter adjustment menu; 4-4 Select 'V LINE' and 'V SCURVE' by pressing 'PROG+' key and 'PROG-' key; press 'VOL+' key and 'VOL-' and adjust corresponding parameter to obtain picture's vertical pin cushion a good status.
-
Page 5: Notes
10-2 Before exit warm up line, press 'factory' key three times continue, at this time exit warm up mode , there is no signal and will appear LOGO pattern. NOTES: 1.Connect the remote IC PIN7 and PIN16 through a jiggle switch on the custom remote handset , this switch is defined as "screen"... -
Page 6: Colour Purity And Convergence Adjustment
COLOUR PURITY AND CONVERGENCE ADJUSTMENT !" # $% #& $'()# * +($'# $% # ',!+#'$!)' -. # ! !" # $% #)% #-/0$'+! 1 + 2, ( +11!"... -
Page 7: Block Diagram
)) # " # # + ' + , $ ...
